HPV110+HMF110 Wheat Harvester Hydrostatic Transmission Strong Driving Force

HPV110+HMF110 wheat harvester Hydrostatic transmission Strong driving force

Quick Detail:

· Cast iron housing

· Hydraulic components

· Model HPV110+HMF110

· Power components of hydraulic systems

· Higher efficiency

· Net weight 143kg

· Simple layout

· Application wheat harvester

· System Solutions

· Work fast

· Fully replace imported products

· Patent certificate certification

· 1 year warranty

Agricultural machinery introduce

The hydraulic pump is one of the core components in the hydrostatic transmission system. Its function is to suck the liquid in the oil tank, compress it into high-pressure liquid, and output it to various hydraulic components in the hydraulic system to realize power transmission and control.

The hydraulic pump acts like the engine pump in the engine and is the power source of the hydraulic system. When the hydraulic pump is running, it will suck the liquid in the oil tank through the negative pressure generated by the mechanical method, and then compress the liquid into high-pressure liquid through the plunger or gear in the mechanical pump body, and then output it to the system through the output port middle.

The output pressure and flow of the hydraulic pump are its important performance indicators, and these parameters are usually selected according to the working requirements of the system. Generally, the output pressure of the hydraulic pump should be high enough to deliver hydraulic oil to all hydraulic components in the system, and its output flow should be large enough to ensure the efficient operation of the system.

Specifications

HPV and HMF Series Technical parameter

Notices

Hydraulic oil

The suitable replacement period for hydraulic oil in a sealed tank system is 2000 hours, and more often if the hydraulic oil is contaminated with water or other external materials or subjected to abnormal operating conditions.

As a general recommendation, the 10µ inlet oil filter should be replaced every spring or every 1500 hours (whichever occurs first) on a sealed tank system, or in an open tank system with an air filter fill cap. The oil filter should be replaced every 500 hours.

Heat Exchanger

The heat exchanger core and fins are kept clean at all times for maximum cooling and system efficiency, and the exterior of the heat exchanger is checked daily for blockages and cleaned as needed.

Application:

Mixer truck: concrete mixer truck, cement mixer truck;

Coal mining machinery: scraper;

Industry: pharmaceutical machinery;

Transport vehicles: road rollers, concrete pump trucks, stabilized soil mixers

FAQ

Q1. Can I have a sample order for wheat harvester hydraulic drive system?

A: Yes, we welcome sample order to test and check quality.

Q2. What about the lead time?

10 to 15 days for samples, mass production according to MOQ

Q3. Do you have any MOQ limit for wheat harvester hydraulic drive system?

A: Low MOQ, 1pc for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

Ship by sea, it generally takes 15-20 days to arrive, and air is also optional.

Q5. How to proceed an order for wheat harvester hydraulic drive system?

A: Firstly let us know your requirements or application.

Secondly We quote according to your requirements or our suggestions.

Thirdly customer confirms the samples and places deposit for formal order.

Fourthly We arrange the production.

Q6: Do you offer guarantee for the products?

A: Yes, we offer 1 years warranty to our products.

Q7: How to deal with the faulty?

Firstly, our products are produced in strict quality control system.Secondly, we will inspect the defective pump and motor, and then respond according to the actual situation.
