Product Details:
|
| Features: | Reliable Quality | Model: | LMF90 |
|---|---|---|---|
| Type: | Hydraulic Components | Material: | Cast Iron |
| Application: | Stove Car Hydraulic Piston Motor | Function: | Hydraulic System Components |
| Medium: | Hydraulic Oil | Warranty: | 1 Year |
| Package: | Plywood Case | Product Name: | EcoMax LMF30 Hydraulic Piston Motors With Innovative Eco-Friendly Technology |
| Highlight: | Stove Car Heavy Duty Hydraulic Motors,Stove car Hydraulic Piston Motors,High Precision Hydraulic Piston Motors |
||
EcoMax LMF30 Hydraulic Piston Motors with Innovative Eco-Friendly Technology
Quick Detail:
· Cast iron housing
· Hydraulic components
· Model LMF30
· Hydraulic system power components
· Principle hydraulic transmission
· Features reliable quality
· Simple layout
· System Solutions
· Work fast
· Fully replace imported products
· Patent certificate certification
· Application drying machinery Hydraulic Piston
· 1 year warranty
Description:
Unlock the full potential of your industrial operations with our high-performance hydraulic piston motors. These motors are a testament to innovative engineering, leveraging the robustness of high-pressure hydraulics to activate pistons with unmatched efficiency and force. The result is a powerful conversion of hydraulic energy into rotational motion, providing both exceptional torque and precise control. Designed for the demanding needs of heavy industry, our hydraulic piston motors set new standards in both performance and dependability. They are particularly suited for challenging environments where both power and precision are key, such as in demanding construction scenarios or precision-based manufacturing. With our motors, industries can harness a combination of strength and finesse, essential for pushing the boundaries of industrial innovation.
Specifications:
LMF Series Technical parameter
| LMF hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HPV series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
Notices:
a. Preventative Maintenance Schedule: Establish and adhere to a regular maintenance schedule. This proactive approach helps in early identification and resolution of potential issues, thereby preventing unexpected breakdowns.
b. System Cleanliness: Keep the hydraulic system clean. Contamination in the system, such as dirt or debris, can cause significant damage to the motor and other hydraulic components.
c. Pressure Regulation: Monitor and regulate the hydraulic pressure consistently. Excessive or fluctuating pressure can strain the motor, leading to premature wear or failure.
d. Vibration Analysis: Regularly analyze vibrations in the motor and connected components. Unusual vibrations can be indicators of underlying issues like imbalance or misalignment.
e. Emergency Protocols: Develop and train personnel in emergency protocols specific to hydraulic piston motor operations. This ensures quick and effective responses to any operational emergencies, safeguarding both personnel and equipment.
Application:
Mixer truck: concrete mixer truck, cement mixer truck;
Coal mining machinery: scraper;
Industry: pharmaceutical machinery;
Transport vehicles: road rollers, concrete pump trucks, stabilized soil mixers
FAQ
Q1. Can I have a sample order for stove car hydraulic piston motor?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
10 to 15 days for samples, mass production according to MOQ
Q3. Do you have any MOQ limit for stove car hydraulic piston motor?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
Ship by sea, it generally takes 15-20 days to arrive, and air is also optional.
Q5. How to proceed an order for stove car hydraulic piston motor?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6: Do you offer guarantee for the products?
A: Yes, we offer 1 years warranty to our products.
Q7: How to deal with the faulty?
Firstly, our products are produced in strict quality control system.Secondly, we will inspect the defective pump and motor, and then respond according to the actual situation.
