Highland Brand HPV110-MA-R-23 Manual Variable Hydraulic Plunger Axial Piston Pump

Highland Brand HPV110-MA-R-23 Manual Variable Hydraulic Plunger Axial Piston Pump
Highland Brand HPV110-MA-R-23 Manual Variable Hydraulic Plunger Axial Piston Pump
Highland Brand HPV110-MA-R-23 Manual Variable Hydraulic Plunger Axial Piston Pump Highland Brand HPV110-MA-R-23 Manual Variable Hydraulic Plunger Axial Piston Pump Highland Brand HPV110-MA-R-23 Manual Variable Hydraulic Plunger Axial Piston Pump Highland Brand HPV110-MA-R-23 Manual Variable Hydraulic Plunger Axial Piston Pump

Large Image :  Highland Brand HPV110-MA-R-23 Manual Variable Hydraulic Plunger Axial Piston Pump

Product Details:
Place of Origin: CHINA DEZHOU
Brand Name: HIGHLAND
Certification: PATENT CERTIFICATE
Model Number: HPV110-MA-R-23
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiated price
Packaging Details: Plywood case
Delivery Time: 8 working days
Payment Terms: T/T
Supply Ability: 100 sets per month

Highland Brand HPV110-MA-R-23 Manual Variable Hydraulic Plunger Axial Piston Pump

Description
Model: HPV110 Piston Hydraulic Pumps Max Displacement: HPV110 Model With 110ml/r Displacement
Max Pressure: 42Mpa Instant Pressure Structure: Variable Displacement Piston
Usage: Combine Harvester, Mixer Truck And Tractor Etc Type: Hydraulic Power Component
Color: Black Warranty: 1 Year
Highlight:

Hydraulic Plunger Axial Piston Pump

,

HPV110 Axial Plunger Pump

,

Manual Axial Plunger Pump

Highland Brand HPV110-MA-R-23 Manual Variable Hydraulic Plunger Axial Piston Pump



Hydraulic Plunger Axial Piston Pump introduction:



Almost every hydraulic applications use hydraulic pumps. A pump performs the task of converting mechanical energy into hydraulic energy. Our hydraulic plunger axial piston pumps have wide range of displacements: Offering a range of pumps with 30-130 cm² per round, multiple displacements specification can match many power machineries. Agricultural machinery, Forestry equipment, mining machinery, construction machinery, combine harvesters, mixer trucks ... use the applications of hydraulic pumps. Nowadays HPV110-MA-R-23 hydraulic piston pumps are very popular all over the world especially in Russia.



Hydraulic plunger axial piston pumps features:



1. High efficiency, durable, robust design meets the demands of harsh work conditions for applications

2. Hydraulic piston pumps have swash plate structure.

3. Be Suitable for closed-loop circuit system.

4. Hydraulic pumps have manual servo and hydraulic variable control mode.

5. Hydraulic pumps are variable displacement pumps with a charging oil pump.
6. Compact design and economical.
7. Optimum volumetric efficiency.

8. Favourable bearing load

9. Top quality.

10. Competitive price.

Highland Brand HPV110-MA-R-23 Manual Variable Hydraulic Plunger Axial Piston Pump 0

Maual Variable Hydraulic Plunger Axial Piston Pump Technical Specification:



HPV Series Technical parameter
HPV hydraulic pump and HMF hydraulic motor series 30 50 70 90 110 130
Displacement Max displacement ml/r 30 50 70 90 110 130
Speed Max continuous working speed
(Full load condition)
r/min 3500 3500 3200 3200 2900 2900
Rated speed r/min 2500
Min continuous working speed r/min 500
Pressure Rated working pressure Mpa 35
Max working pressure (transient) Mpa 42
Continuous working pressure Mpa 30
Allowable shell pressure (Absolute) Mpa Constant0.25, Peak value0.5
Torque Continuous output torque
(Under continuous working pressure)
Nm 162.3 252.3 342.6 432.9 535.3 632.4
Max output torque Nm 227 353 480 606 749 885
Power Continuous output power KW 45 79 107 139 149 176
Max power KW 62 95 114 150 173 205
Temperature Allowable shell temperature 80
Max working temperature of oil tank 70
Weight

HPV series hydraulic pump

hydraulic oil emptying

kg 45 46 63 64 82 88

HMF series hydraulic motor

hydraulic oil emptying

kg 30 30 36 36 36 38


Highland Brand HPV110-MA-R-23 Manual Variable Hydraulic Plunger Axial Piston Pump 1

Highland after-sale service:



Quality service

One to one service, can provide design and installation solutions;

Online service for quick response and consultation;

Free door-to-door service to solve difficult after-sales problems;



Fast delivery and good service

A number of invention patents and utility model patent certification, the key components of imported raw materials; Order 7 ~ 20 days fast delivery, 1 year after sales maintenance cycle, for your risk.



FAQ of hydraulic piston pumps:



Q1: Could I have a sample order?

A: Yes, we welcome a sample order to test and check quality.



Q2: How do you ship the goods and how long does it take to arrive?

A: Shipping way depends on quantity, if 1-2 set, ship by air express, it takes 3-5 days to arrive. Or shipping by sea.



Q3: Do you offer guarantee for the products?

A: No one can match our dedication to quality, honesty and value. Experienced hydraulic pump experts, experienced customer service, experienced technicians dedicated to their work, process each and every order. Each order is carefully inspected before it leaves our facility.

Also we offer 1 year gurantee.



Q4: What are the payment terms?

A: Full order: 30% as deposit, balance paid before shipment.

Small order/sample order: Full advance payment.



Q5: Are you manufacturer?

We are a manufacturer with own plant manufacturing producing hydraulic pumps and motors.

20 years experience in hydraulic industry for oversea and domestic markets. Main business range is hydraulic motor pump system, piston pumps and motors, welcome to visit our factory in Dezhou city Shandong province.

Highland Brand HPV110-MA-R-23 Manual Variable Hydraulic Plunger Axial Piston Pump 2

Tag: HPV110-MA-R-23, manual axial piston pump, hydraulic plunger pump
