Product Details:
|
| Model: | HPV70+HMF70 | Type: | Hydraulic Components |
|---|---|---|---|
| Net Weight: | 108 Kg | Material: | Cast Iron |
| Application: | Wheat Harvester | Medium: | Hydraulic Oil |
| Warranty: | 1 Year | Function: | Hydraulic System Components |
| Package: | Plywood Case | Product Name: | Harnessing The Power Of Fluids: An Introduction To Hydrostatic Transmissions |
| Highlight: | Hydraulic oil Hydrostatic Transmissions,Hydrostatic Transmissions For Wheat harvester,HPV70+HMF70 Hydrostatic Transmissions |
||
Harnessing the Power of Fluids: An Introduction to Hydrostatic Transmissions
Quick Detail:
· Cast iron housing
· Hydraulic components
· Model HPV70+HMF70
· Power components of hydraulic systems
· Higher efficiency
· Net weight 108kg
· Simple layout
· Application wheat harvester
· System Solutions
· Work fast
· Fully replace imported products
· Patent certificate certification
· 1 year warranty
Agricultural machinery introduce
A Hydrostatic Transmission is a type of power transmission system that utilizes pressurized hydraulic fluid to transfer power from the engine to the other components of a machine. It's highly efficient and offers smooth, variable speed control, making it ideal for heavy machinery and industrial applications.
Specifications
HPV and HMF Series Technical parameter
| LPV hydraulic pump and LMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| weight | LPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| LPV series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
Notices
Regular Maintenance: Regular maintenance of a Hydrostatic Transmission is crucial to ensure its longevity and optimal performance. This includes checking hydraulic fluid levels and replacing it when necessary, as well as inspecting for leaks or signs of wear in the system.
Application:
Mixer truck: concrete mixer truck, cement mixer truck;
Coal mining machinery: scraper;
Industry: pharmaceutical machinery;
Transport vehicles: road rollers, concrete pump trucks, stabilized soil mixers
FAQ
Q1. Can I have a sample order for wheat harvester hydraulic drive system?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
10 to 15 days for samples, mass production according to MOQ
Q3. Do you have any MOQ limit for wheat harvester hydraulic drive system?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
Ship by sea, it generally takes 15-20 days to arrive, and air is also optional.
Q5. How to proceed an order for wheat harvester hydraulic drive system?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6: Do you offer guarantee for the products?
A: Yes, we offer 1 years warranty to our products.
Q7: How to deal with the faulty?
Firstly, our products are produced in strict quality control system.Secondly, we will inspect the defective pump and motor, and then respond according to the actual situation.
