Product Details:
|
| Model: | HPV70+HMF70 | Type: | Hydraulic Components |
|---|---|---|---|
| Net Weight: | 108 Kg | Material: | Cast Iron |
| Application: | Wheat Harvester | Medium: | Hydraulic Oil |
| Warranty: | 1 Year | Function: | Hydraulic System Components |
| Package: | Plywood Case | Product Name: | Harnessing The Power Of Fluids: An Introduction To Hydrostatic Transmissions |
| Highlight: | Hydrostatic Transmission HMF70,Hydraulic Hydrostatic Transmission,Wheat Harvester Hydrostatic System |
||
Harnessing the Power of Fluids: An Introduction to Hydrostatic Transmissions
Quick Detail:
· Cast iron housing
· Hydraulic components
· Model HPV70+HMF70
· Power components of hydraulic systems
· Higher efficiency
· Net weight 108kg
· Simple layout
· Application wheat harvester
· System Solutions
· Work fast
· Fully replace imported products
· Patent certificate certification
· 1 year warranty
Agricultural machinery introduce
Implementing a Hydrostatic Transmission system signifies the use of pressurized hydraulic fluid to effectively transmit power from the engine to the other components within a machine. Its superior efficiency coupled with smooth, variable speed control makes it particularly suitable for applications involving heavy machinery and industrial equipment.
Specifications
HPV and HMF Series Technical parameter
| LPV hydraulic pump and LMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| weight | LPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| LPV series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
Notices
System Monitoring: Consistent monitoring of a Hydrostatic Transmission system is vital for its prolonged durability and superior functionality. This involves a routine check of the hydraulic fluid levels and timely replacements when required. Additionally, regular inspections for any leakages or signs of wear and tear in the system are paramount.
Scheduled Servicing: Upholding a regular maintenance schedule for a Hydrostatic Transmission can greatly enhance its lifespan and performance. This entails keeping an eye on the hydraulic fluid levels and replacing it when needed. Regular system checks for any leaks or wear indicators are also essential to prevent any potential malfunctions.
Application:
Mixer truck: concrete mixer truck, cement mixer truck;
Coal mining machinery: scraper;
Industry: pharmaceutical machinery;
Transport vehicles: road rollers, concrete pump trucks, stabilized soil mixers
FAQ
Q1. Can I have a sample order for wheat harvester hydraulic drive system?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the lead time?
10 to 15 days for samples, mass production according to MOQ
Q3. Do you have any MOQ limit for wheat harvester hydraulic drive system?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the goods and how long does it take to arrive?
Ship by sea, it generally takes 15-20 days to arrive, and air is also optional.
Q5. How to proceed an order for wheat harvester hydraulic drive system?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6: Do you offer guarantee for the products?
A: Yes, we offer 1 years warranty to our products.
Q7: How to deal with the faulty?
Firstly, our products are produced in strict quality control system.Secondly, we will inspect the defective pump and motor, and then respond according to the actual situation.
