Highland High Pressure High Efficiency Concrete Mixer Hydraulic Piston Pumps
High Efficiency Hydraulic Piston Pump Product Description:
We offer a range of static hydraulic transmission products that deliver high-quality and high-performance parameter solutions. Our HPV90 hydraulic pumps are variable, featuring a charge pump. They can be manual operated or hydraulically operated to easily control speed, direction, and power of the output shaft of the hydraulic motor. This is an ideal hydraulic equipment for customers who require reliable and efficient pieces of high-performing equipment.
Concrete Mixer Hydraulic Piston Pump Features:
HPV90 hydraulic pump is one of the most popular and trusted pumps among hydraulic pumps. It has various features that make it a viable choice for many diverse applications.
Firstly, it has an axial variable displacement piston pump. This provides better control over the amount of fluid delivered, making it suitable for many applications which require precision and accuracy.
The pump also utilizes a swash plate structure, allowing for a wide range of displacement and speed. This also allows the pressure to be increased or decreased, which is suitable for various applications.
Additionally, HPV90 is suitable for hydrostatic transmissions using closed loop circuits. This is beneficial for applications where the amount of power needed must be controlled precisely.
Lastly, manual servo and hydraulic variable control are available in the HPV90. This gives the user more control over the operation of the pump and can be beneficial in many different applications.
Hydraulic piston pump technical parameters:
| HPV Series Technical parameter | ||||||||
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HPV series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
High Efficiency Hydraulic Piston Pump Applications:
Our HPV90 hydraulic piston pumps are renowed for being carefully processed and reliable in quality. Plus, we are sure to deliver promptly. Furthermore, we are devoted to provide our customers with quality services in the selection and use of static hydraulic equipment. These hydraulic pumps are widely used in agricultural machines such as combine harvesters, engineering machines like concrete mixer trucks, mining LHD trucks, and related aviation and agricultural machinery. They are particularly suitable for hydraulic engineering.
Hydraulic Piston Pump FAQ:
Q1: Could I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q2: How do you ship the goods and how long does it take to arrive?
A: Ship by air express, it takes 3-5 days to arrive. Airline and sea shipping also optional.
Q3: Do you offer guarantee for the products?
A: Each motor or pump should be tested before shipping, test report can be sent if requested.
Warranty 12 months after shipment for complete assembly.
Q4: What are the payment terms?
A: Full order: 40% as deposit, balance before shipment.
Small order/sample order: Full advance payment.
Q5: Are you manufacturer?
We are a manufacturer with own plant manufacturing hydraulic motor pump system.
20 years experience in hydraulic industry for oversea and domestic markets. Main business range is hydraulic motor pump system, piston pumps and motors, welcome to visit our factory in Dezhou city Shandong province.
