Product Details:
|
| Product Name: | Heavy Duty Hydraulic Axial Piston Pump For Construction Machinery | Power Source: | Hydraulic |
|---|---|---|---|
| Material: | Cast Iron | Max Pressure: | 42Mpa |
| Rated Pressure: | 35Mpa | Type: | Piston Pump |
| Standard Export Package: | Plywood Case | Warranty: | 1 Year |
| Color: | Black | ||
| Highlight: | Construction Machinery Hydraulic Axial Piston Pump,Heavy Duty Variable Displacement Piston Pump |
||
Hydraulic piston pump is a significant component in the hydraulic system, which utilizes the oscillating motion of a plunger within a cylinder body to alter the amount of the sealed working chamber, so as to obtain oil absorption and oil pressure.
Plunger pumps involve many advantages, such as high rating pressure, neat structure, great efficiency, as well as easy flow adjustment. As a result, they are employed in occasions requiring high-pressure, huge flow, and adjustable flow.
Technical Parameters:
| HPV Series Technical parameter | ||||||||
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
Hydraulic piston pumps are widely used in high-pressure, high-flow, high-power systems and occasions where the flow needs to be adjusted, such as agricultural machinery, construction machinery, mining and metallurgical machinery, and ships. It can play an important role.
In addition, these pumps can also be commonly used in petroleum exploration and development, petrochemical, pharmaceutical, atomic energy science, environmental science, process equipment, experimental equipment, and more. They are essential in many industries including aerospace, coal mining, and shipbuilding.
We package Hydraulic Piston Pumps in sturdy plywood boxes, ensuring that they are secure and protected from damage during shipping. We also use plastic bag and other packing materials to provide additional protection. We ship Hydraulic Piston Pumps by air, sea, and ground, depending on the customer's needs.
Q1: What is the Brand Name of the Hydraulic Piston Pumps?
A1: The Brand Name of the Hydraulic Piston Pumps is HIGHLAND.
Q2: What is the Model Number of the Hydraulic Piston Pumps?
A2: The Model Number of the Hydraulic Piston Pumps is HPV110.
Q3: Where is the place of origin of the Hydraulic Piston Pumps?
A3: The place of origin of the Hydraulic Piston Pumps is CHINA DEZHOU.
Q4: What is the certification of the Hydraulic Piston Pumps?
A4: The certification of the Hydraulic Piston Pumps is PATENT CERTIFICATE.
Q5: What is the Minimum Order Quantity of the Hydraulic Piston Pumps?
A5: The Minimum Order Quantity of the Hydraulic Piston Pumps is 5 Sets.
