Product Details:
|
| Max Pressure: | 42Mpa | Rated Pressure: | 35Mpa |
|---|---|---|---|
| Package: | Plywood Case | Pressure Range: | High Pressure |
| Type: | Piston Pump | Color: | Black |
| Structure: | Variable Displacement Piston Pump | Power Source: | Hydraulic |
| Highlight: | Agricultural Hydraulic Piston Pump 35Mpa,Agricultural Hydraulic Variable Displacement Piston Pump |
||
Hydraulic piston pumps are ideal for agricultural harvesters and mixer trucks that require high pressure and superior performance. Our hydraulic piston pumps provide maximum pressure of up to 42MPa, and have a robust design that ensures reliable operation. We offer piston pumps in a variety of different sizes and types, so you can find the perfect pump for your application. All of our piston pumps come with a standard export package of a plywood case for secure shipping and storage.
We provide hydraulic piston pumps for sale for a wide range of applications and industries, including industrial, agricultural, construction, and more. Our piston pumps are designed for reliability, efficiency, and performance, and are easy to install and maintain. Our high pressure piston pumps provide superior performance and long lasting durability. With our wide selection of hydraulic piston pumps, you can find the perfect pump for your needs.
If you are looking for a reliable, high performance piston pump for your agricultural harvester or mixer truck, look no further than our selection of hydraulic piston pumps. With our selection of sizes and types, you are sure to find the perfect pump for your application. All of our piston pumps come with a standard export package of a plywood case for secure shipping and storage.
Technical Parameters:| Parameter | Value |
|---|---|
| Application | Agricultural Harvester Or Mixer Truck |
| Max Pressure | 42Mpa |
| Pressure Range | High Pressure |
| Power Source | Hydraulic |
| Hydraulic System | Closed Loop Hydraulic Pump |
| Package | Plywood Case |
| Color | Black |
| Function | Hydraulic System Components |
| Warranty | 1 Year |
| Principle | Hydraulic Transmission |
| Product | Hydraulic Piston Pumps |
| Keywords | hydraulic piston pump, piston pump for sale, high pressure piston pump |
Hydraulic piston pumps technical specification:
| HPV Series Technical parameter | ||||||||
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HPV series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 |
38 |
|
Applications:HIGHLAND HPV110 hydraulic piston pumps are designed to meet the needs of various working conditions. It has a structure of variable displacement piston pump and a power source of hydraulic. The product is from Dezhou, China, and comes with a patent certificate. The minimum order quantity is 5 sets, and the price range is USD900-1400/set. The packaging details are plywood case, and the delivery time is 10 working days. Payment methods include T/T, Western Union, and the supply ability is 400 sets/month. The standard export package is a plywood case, and the color is black. It also comes with a 1 year warranty.
We are committed to providing our customers with the highest level of technical support and service for our hydraulic piston pumps. Our team of experienced engineers and technicians is available to answer any questions and provide guidance on the installation, operation, and maintenance of our products.
In addition to our technical support and service, we offer a range of training programs to ensure that our customers are fully trained in the use of our products. Our goal is to provide the best possible service and expertise to ensure that our customers get the most out of their hydraulic piston pumps.
If you have any questions or need any assistance, please do not hesitate to contact us. Our team is always here to help.
Brand Name: HIGHLAND
Model Number: HPV110
Place of Origin: CHINA DEZHOU
Certification: PATENT CERTIFICATE
Minimum Order Quantity: 5 Sets
Price: USD900-1400/Set
Packaging Details: Plywood Case
Delivery Time: 10 Working Days
Payment Terms: T/T, Western Union
Supply Ability: 400 Sets/Month
