Product Details:
|
| Standard Export Package: | Plywood Case | Package: | Plywood Case |
|---|---|---|---|
| Structure: | Variable Displacement Piston Pump | Principle: | Hydraulic Transmission |
| Color: | Black | Max Pressure: | 42Mpa |
| Hydraulic System: | Closed Loop Hydraulic Pump | Product Name: | Hydraulic Piston Pumps |
| Highlight: | Hydraulic Power Transmission Piston Pumps,Closed Loop Hydraulic Pump 42Mpa |
||
Hydraulic Piston Pumps are one of the most versatile solutions for efficient hydraulic power transmission. Featuring a high pressure range, these HPV110 hydraulic pumps are capable of providing reliable operation for a variety of applications. The piston pump design results in a robust package with excellent durability and consistent performance. Our hydraulic piston pumps are available in a variety of sizes to suit your specific needs. Each pump is packed in a sturdy plywood case for secure transportation and storage. All of our piston pumps come with a one-year warranty for your peace of mind. Whether you’re looking for a powerful and reliable solution for your hydraulic system or require a robust piston pump for sale, our HPV110 hydraulic pumps are the perfect choice.
Technical Parameters:| Characteristic | Details |
|---|---|
| Material | Cast Iron |
| Pressure Range | High Pressure |
| Product Name | Hydraulic Piston Pumps |
| Principle | Hydraulic Transmission |
| Type | Piston Pump |
| Structure | Variable Displacement Piston Pump |
| Max Pressure | 42Mpa |
| Color | Black |
| Standard Export Package | Plywood Case |
| Warranty | 1 Year |
Hydraulic piston pumps technical specification:
| HPV Series Technical parameter | ||||||||
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HPV series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 |
38 |
|
Applications:Hydraulic piston pumps, like the HIGHLAND HPV110 model, are essential in many applications. Their high pressure and precise control makes them ideal for a wide range of operations. This PATENT CERTIFICATE hydraulic piston pump is designed for agricultural harvester or mixer truck, with a rated pressure of 35Mpa and maximum pressure of 42Mpa. The minimum order quantity is 5 sets, and the price range is from USD900 to USD 1400 each set. The packaging is plywood case, and the delivery time is within 10 working days. The payment terms are T/T or Western Union, and the supply ability is 400 sets per month.
We provide technical support and service for Hydraulic Piston Pumps to ensure your satisfaction with our product. Our team of experienced technicians is available to answer any questions you may have regarding installation, operation, and troubleshooting. We also offer service and maintenance to keep your Hydraulic Piston Pumps running smoothly.
We provide a comprehensive warranty and service plan for all our Hydraulic Piston Pumps. In addition, we provide free technical support for all our products.
If you need assistance with your Hydraulic Piston Pumps, please contact our customer service team. We are available 24 hours a day, seven days a week to answer any questions you may have and provide you with the best possible service.
Q1: What is the brand name of the hydraulic piston pump?
A1: The brand name of the hydraulic piston pump is HIGHLAND.
Q2: What is the model number of the hydraulic piston pump?
A2: The model number of the hydraulic piston pump is HPV110.
Q3: Where is the hydraulic piston pump manufactured?
A3: The hydraulic piston pump is manufactured in Dezhou, China.
Q4: What is the minimum order quantity of the hydraulic piston pump?
A4: The minimum order quantity of the hydraulic piston pump is 5 sets.
Q5: What is the price range and payment terms for the hydraulic piston pump?
A5: The price range for the hydraulic piston pump is USD900-1400/set and the payment terms are T/T or Western Union.
