Product Details:
|
| Hydraulic System: | Closed Loop Hydraulic Pump | Product Name: | Hydraulic Piston Pumps |
|---|---|---|---|
| Max Pressure: | 42Mpa | Package: | Plywood Case |
| Structure: | Variable Displacement Piston Pump | Warranty: | 1 Year |
| Rated Pressure: | 35Mpa | Material: | Cast Iron |
Hydraulic Piston Pumps are high quality hydraulic pumps perfect for high pressure applications. These pumps are made of durable materials, and their high pressure range makes them ideal for tough jobs. They are also available in black and come with a 1 year warranty for added peace of mind. The standard export package is a plywood case, and the power source is hydraulic, making them an efficient and reliable choice. Get a high pressure piston pump today and experience the difference in quality and performance. With premium features and unbeatable performance, these piston pumps are the perfect solution for your needs. Invest in a high quality hydraulic pump and enjoy the convenience and reliability of a piston pump for sale.
| Parameter | Value |
|---|---|
| Package | Plywood Case |
| Pressure Range | High Pressure |
| Color | Black |
| Max Pressure | 42Mpa |
| Type | Piston Pump |
| Power Source | Hydraulic |
| Principle | Hydraulic Transmission |
| Rated Pressure | 35Mpa |
| Hydraulic System | Closed Loop Hydraulic Pump |
| Standard Export Package | Plywood Case |
| High Quality Hydraulic Pump | LPV110 Hydraulic Pump |
| LPV Series Technical parameter | ||||||||
| LPV hydraulic pump and LMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| weight | LPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| LPV series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
Hydraulic piston pumps, with brand name HIGHLAND and model number LPV110, are widely used in hydraulic system components and have earned PATENT CERTIFICATE from CHINA DEZHOU. With minimum order quantity of 5 sets, they are priced USD900-1400/Set and supplied in Plywood Case. The color of the hydraulic pump is black and the max pressure is 42Mpa. Delivery time is 10 working days and payment terms are T/T, Western Union. The products are backed by 1 year warranty and the supply ability is 200 sets/month.
We provide technical support and service for all our hydraulic piston pumps. Our technical support team is available 24/7 to answer any questions or concerns you may have about our pumps. We also provide a comprehensive warranty for all our products, so you can trust that our products are of the highest quality.
We have an extensive selection of parts and accessories, as well as replacement parts, to ensure that your hydraulic piston pump remains in peak condition. We also offer a variety of maintenance and repair services, so you know your pump is always up and running.
We understand that our customers have different needs, so we offer custom solutions tailored to each individual situation. Our team of experienced technicians can work with you to design and install a system that meets your exact requirements.
For more information on our technical support and service for hydraulic piston pumps, please contact us today. We look forward to hearing from you.
