Product Details:
|
| Color: | Black | Principle: | Hydraulic Transmission |
|---|---|---|---|
| Application: | Agricultural Harvester Or Mixer Truck | Function: | Hydraulic System Components |
| Rated Pressure: | 35Mpa | Standard Export Package: | Plywood Case |
| Structure: | Variable Displacement Piston Pump | Material: | Cast Iron |
Hydraulic piston pumps are high quality hydraulic pumps designed to provide powerful and efficient performance. Our HPV110 hydraulic pump is perfect for closed loop hydraulic systems, and is constructed with a durable black casing for protection. This hydraulic pump can provide a high pressure range, and is powered by hydraulic power source. Our hydraulic piston pumps come packaged in a sturdy plywood case, designed to provide long lasting protection.
Our HPV110 hydraulic pump is the perfect choice for any hydraulic system that requires a reliable, high quality solution. Our hydraulic pump is designed to offer maximum performance and efficiency, and is capable of providing a powerful and consistent pressure range. The durable black casing helps protect the hydraulic pump from damage, and the plywood case ensures that the pump is securely packaged for easy transport and storage.
Whether you need a reliable hydraulic pump for your closed loop hydraulic system or a powerful and efficient solution for any other hydraulic system, our HPV110 hydraulic piston pump is the perfect choice. With its durable construction, high pressure range, and powerful hydraulic power source, our hydraulic pump provides you with a long lasting and reliable solution. Invest in our HPV110 hydraulic pump today and enjoy the powerful performance and peace of mind that comes with it.
| Parameters | Details |
|---|---|
| Function | Hydraulic System Components |
| Pressure Range | High Pressure |
| Warranty | 1 Year |
| Principle | Hydraulic Transmission |
| Application | Agricultural Harvester Or Mixer Truck |
| Power Source | Hydraulic |
| Color | Black |
| Structure | Variable Displacement Piston Pump |
| Standard Export Package | Plywood Case |
| Max Pressure | 42Mpa |
| LPV Series Technical parameter | ||||||||
| LPV hydraulic pump and LMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| weight | LPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| LPV series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
Highland hydraulic provide comprehensive technical support and services for our hydraulic piston pumps. Our team of experts have extensive knowledge and experience in providing reliable and efficient solutions to all your needs. We offer a full range of services including:
We strive to provide the highest quality of customer service and technical support. Our team is available 24/7 to answer any questions you may have and provide timely and effective solutions. We are committed to delivering excellent service and ensuring that your hydraulic piston pumps are working to their fullest potential.
Q: What is the brand name of the Hydraulic Piston Pumps?
A: The brand name of the Hydraulic Piston Pumps is HIGHLAND.
Q: What is the model number of the Hydraulic Piston Pumps?
A: The model number of the Hydraulic Piston Pumps is LPV110.
Q: Where is the Hydraulic Piston Pumps manufactured?
A: The Hydraulic Piston Pumps is manufactured in DEZHOU, CHINA.
Q: What is the minimum order quantity of the Hydraulic Piston Pumps?
A: The minimum order quantity of the Hydraulic Piston Pumps is 5 Sets.
Q: What is the price of the Hydraulic Piston Pumps?
A: The price of the Hydraulic Piston Pumps is between USD900-1400/Set.
