Black Hydraulic Piston Pump With Variable Displacement For Agriculture Industry

Black Hydraulic Piston Pump With Variable Displacement For Agriculture Industry
Black Hydraulic Piston Pump With Variable Displacement For Agriculture Industry Black Hydraulic Piston Pump With Variable Displacement For Agriculture Industry Black Hydraulic Piston Pump With Variable Displacement For Agriculture Industry

Large Image :  Black Hydraulic Piston Pump With Variable Displacement For Agriculture Industry

Product Details:
Place of Origin: CHINA DEZHOU
Brand Name: HIGHLAND
Certification: PATENT CERTIFICATE
Model Number: HPV110
Payment & Shipping Terms:
Minimum Order Quantity: 5 Sets
Price: USD900-1400/Set
Packaging Details: Plywood Case
Delivery Time: 10 Working Days
Payment Terms: T/T, Western Union
Supply Ability: 200 Sets/Month

Black Hydraulic Piston Pump With Variable Displacement For Agriculture Industry

Description
Material: Cast Iron Pressure Range: High Pressure
Hydraulic System: Closed Loop Hydraulic Pump Structure: Variable Displacement Piston Pump
Application: Agricultural Harvester And Tractor Principle: Hydraulic Transmission
Function: Hydraulic System Components Warranty: 1 Year
Highlight:

Hydraulic Piston Pump With Variable Displacement

,

Agriculture Industry Hydraulic Piston Pump

Black Hydraulic Piston Pump with Variable Displacement for Agriculture Industry

Product Description:

Hydraulic Piston Pumps - The Ultimate Solution for High Pressure Hydraulic Systems

Are you looking for a powerful and reliable hydraulic pump for your high pressure hydraulic system? Look no further than our Hydraulic Piston Pumps! Known for their efficiency and durability, our piston pumps are the perfect choice for any hydraulic system.

Power Source: Hydraulic

Our Hydraulic Piston Pumps are powered by hydraulic energy, making them highly efficient and able to handle heavy loads and high pressure situations with ease.

Function: Hydraulic System Components

As vital components of hydraulic systems, our piston pumps play a crucial role in converting mechanical energy into hydraulic energy. This allows for precise and efficient control of fluid flow and pressure within the system.

Structure: Variable Displacement Piston Pump

Our piston pumps feature a variable displacement design, which means they can adjust the displacement of fluid depending on the system's requirements. This allows for greater flexibility and improved performance in various applications.

Hydraulic System: Closed Loop Hydraulic Pump

Our Hydraulic Piston Pumps are designed for use in closed loop hydraulic systems, where the fluid is continuously circulated and reused. This makes them more efficient and reduces the risk of contamination or fluid loss.

Pressure Range: High Pressure

Our piston pumps are specifically designed to handle high pressure situations, with pressure ranges up to 700 bar. This makes them ideal for heavy-duty applications such as construction machinery, industrial presses, and more.

At Hydraulic Piston Pumps, we take pride in providing high quality hydraulic pumps that meet the needs and demands of our customers. Our pumps are designed and manufactured with precision and care to ensure maximum performance and reliability.

So why wait? Get your hydraulic piston pump today and experience the power, efficiency, and durability of our products for yourself! Contact us now for more information or to purchase your very own piston pump.

Black Hydraulic Piston Pump With Variable Displacement For Agriculture Industry 0Features:

  • Product Name: Hydraulic Piston Pumps
  • Structure: Variable Displacement Piston Pump
  • Standard Export Package: Plywood Case
  • Package: Plywood Case
  • Application: Agricultural Harvester And Tractor
  • Key Features:
    • Efficient and reliable hydraulic piston pump
    • Provides variable displacement for enhanced control and flexibility
    • Equipped with HPV110 hydraulic pump for high performance
    • Designed for use in agricultural harvesters and tractors
    • Comes with a standard export package of plywood case for safe transportation
    • Competitive hydraulic piston pump price for cost-effective solutions

Technical Parameters:

HPV hydraulic pump and HMF hydraulic motor series 30 50 70 90 110 130
Displacement Max displacement ml/r 30 50 70 90 110 130
Speed Max continuous working speed
(Full load condition)
r/min 3500 3500 3200 3200 2900 2900
Rated speed r/min 2500
Min continuous working speed r/min 500
Pressure Rated working pressure Mpa 35
Max working pressure (transient) Mpa 42
Continuous working pressure Mpa 30
Allowable shell pressure (Absolute) Mpa Constant0.25, Peak value0.5
Torque Continuous output torque
(Under continuous working pressure)
Nm 162.3 252.3 342.6 432.9 535.3 632.4
Max output torque Nm 227 353 480 606 749 885
Power Continuous output power KW 45 79 107 139 149 176
Max power KW 62 95 114 150 173 205
Temperature Allowable shell temperature 80
Max working temperature of oil tank 70
weight HPV series hydraulic pump hydraulic oil drain kg 45 46 63 64 82 88
HMF series hydraulic motor hydraulic oil drain kg 30 30 36 36 36 38



Parameter Value
Product Name HPV110 Hydraulic Piston Pump
Principle Hydraulic Transmission
Color Black
Type Piston Pump
Hydraulic System Closed Loop
Power Source Hydraulic
Application Agricultural Harvester and Tractor
Structure Variable Displacement Piston Pump
Max Pressure 42Mpa
Warranty 1 Year
Package Plywood Case

Black Hydraulic Piston Pump With Variable Displacement For Agriculture Industry 1Applications:

Highland Hydraulic Piston Pumps - Powerful and Reliable

Are you looking for a high quality hydraulic pump for your industrial or commercial needs? Look no further than HIGHLAND. Our innovative hydraulic piston pumps are designed to provide superior performance and durability, making them the perfect choice for a variety of applications.

Product Overview

The HIGHLAND HPV110 is a top-of-the-line hydraulic piston pump, manufactured in China's Dezhou region. It is an ideal choice for those in need of a high-quality, closed loop hydraulic pump that can handle heavy-duty applications with ease. The patented technology used in our pumps ensures maximum efficiency and longevity, making it a valuable addition to any hydraulic system.

Applications and Scenarios

Our hydraulic piston pumps are widely used in various industries and applications, such as:

  • Construction machinery
  • Marine equipment
  • Mining machinery
  • Agricultural machinery
  • Industrial equipment



With so many hydraulic pumps available on the market, what makes HIGHLAND stand out? Here are a few reasons why our hydraulic piston pumps are the best choice for your hydraulic system:

  • High quality and reliability - Our pumps are made with the highest quality materials and undergo rigorous testing to ensure reliable performance.
  • Efficient hydraulic transmission - The closed loop hydraulic design of our pumps ensures maximum efficiency, reducing energy consumption and saving you money.
  • Expertise in hydraulic technology - With years of experience in the hydraulic industry, we understand the unique needs and challenges of our customers and provide tailored solutions to meet them.
  • Patented technology - Our pumps are equipped with patented technology that sets them apart from other hydraulic pumps on the market.
  • Customizable options - We offer a wide range of options and configurations to meet the specific needs of your application.
  • Excellent customer service - Our dedicated team is available to provide support and assistance throughout the entire process, from choosing the right pump to after-sales service.

FAQ:

  • Q: What is the brand name of this product?
  • A: The brand name of this product is HIGHLAND.
  • Q: What is the model number of this product?
  • A: The model number of this product is HPV110.
  • Q: Where is this product manufactured?
  • A: This product is manufactured in CHINA DEZHOU.
  • Q: Does this product have any certification?
  • A: Yes, this product has a PATENT CERTIFICATE.
  • Q: What is the minimum order quantity for this product?
  • A: The minimum order quantity for this product is 5 sets.
  • Q: What is the price range for this product?
  • A: The price range for this product is USD900-1400 per set.
  • Q: How is this product packaged?
  • A: This product is packaged in a Plywood Case.
  • Q: How long is the delivery time for this product?
  • A: The delivery time for this product is 10 working days.
  • Q: What are the payment terms for this product?
  • A: The payment terms for this product are T/T and Western Union.
  • Q: What is the supply ability for this product?
  • A: The supply ability for this product is 200 sets per month.

Black Hydraulic Piston Pump With Variable Displacement For Agriculture Industry 2
