Product Details:
|
| Max Pressure: | 42Mpa | Pressure Range: | High Pressure |
|---|---|---|---|
| Function: | Hydraulic System Components | Color: | Black |
| Rated Pressure: | 35Mpa | Structure: | Variable Displacement Piston Pump |
| Principle: | Hydraulic Transmission | Power Source: | Hydraulic |
The Hydraulic Piston Pumps are high-quality and reliable pumps that are perfect for use in agricultural harvesters and tractors. With a pressure range of high pressure and a warranty of 1 year, these pumps are designed to meet the demands of heavy-duty machinery.
The Hydraulic Piston Pumps are specifically designed to be used in agricultural harvesters and tractors. These pumps are essential for powering the hydraulic systems in these heavy-duty machines, ensuring smooth operation and maximum productivity.
Our Hydraulic Piston Pumps come with a warranty of 1 year, providing you with added peace of mind and assurance of the quality and durability of our products. In the unlikely event that you encounter any issues with your pump, our dedicated customer service team will be happy to assist you.
The product name, Hydraulic Piston Pumps, perfectly describes the function and purpose of this product. It is a hydraulic pump that uses pistons to move fluid and generate power, making it an essential component in many industries.
Our Hydraulic Piston Pumps are designed to operate under high pressure, making them suitable for use in heavy-duty machinery and demanding applications. This ensures that your equipment can perform at its best, even under tough working conditions.
The Hydraulic Piston Pumps come in a sleek and professional black color, adding a touch of style and sophistication to your machinery. The color also helps to hide any dirt or grime that may accumulate during operation, ensuring that your pump always looks clean and well-maintained.
If you are in need of a reliable and efficient piston pump for your agricultural harvester or tractor, look no further than our Hydraulic Piston Pumps. With its high-quality construction, excellent performance, and reasonable price, it's the perfect choice for your hydraulic system needs.
The Hydraulic Piston Pumps are compatible with the HPV110 hydraulic pump, a popular choice in the industry. This means you can easily replace your old or damaged pump with our Hydraulic Piston Pump without any compatibility issues.
The Hydraulic Piston Pumps are the perfect choice for agricultural harvesters and tractors, offering high-quality, reliable performance and a 1-year warranty. With its high-pressure range, sleek black color, and compatibility with the HPV110 hydraulic pump, it's the ideal solution for all your hydraulic system needs. Get your Hydraulic Piston Pumps today and experience the difference in your machinery's performance!
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil emptying |
kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil emptying |
kg | 30 | 30 | 36 | 36 | 36 | 38 | |
| Product Name | Hydraulic Piston Pumps |
|---|---|
| Function | Hydraulic System Components |
| Principle | Hydraulic Transmission |
| Max Pressure | 42Mpa |
| Material | Cast Iron |
| Rated Pressure | 35Mpa |
| Power Source | Hydraulic |
| Warranty | 1 Year |
| Type | Piston Pump |
| Hydraulic System | Closed Loop Axial Hydraulic Pump |
Hydraulic piston pumps are essential components in hydraulic systems, utilizing the principle of hydraulic transmission to generate high pressures. The Hydraulic Piston Pumps have a maximum pressure of 42Mpa and a rated pressure of 35Mpa, making them ideal for high pressure applications. Made of cast iron, these pumps are durable and reliable. They are powered by hydraulic sources and come with a 1 year warranty. The type of pump is a piston pump, specifically a closed loop axial hydraulic pump.
The Hydraulic Piston Pumps from HIGHLAND, model HPV110, are high-quality, powerful and efficient pumps that are designed for use in agricultural harvesters and tractors. With their impressive pressure range and durable construction, these pumps are the perfect choice for any heavy-duty hydraulic system.
The Hydraulic Piston Pumps from HIGHLAND are ideal for use in a wide range of agricultural machinery and equipment, including:
These pumps are also suitable for use in industrial machinery and equipment, such as construction machinery, excavators, and more.
The Hydraulic Piston Pumps from HIGHLAND are the perfect choice for anyone in need of a high-quality, reliable and efficient hydraulic pump. With their impressive features and benefits, these pumps are sure to enhance the performance of your agricultural machinery and equipment. Order now and experience the power and efficiency of these top-quality piston pumps!
