Product Details:
|
| Structure: | Variable Displacement Axial Piston Pump | Rated Pressure: | 35Mpa |
|---|---|---|---|
| Product Name: | Hydraulic Piston Pumps | Standard Export Package: | Plywood Case |
| Function: | Hydraulic System Components | Pressure Range: | High Pressure |
| Package: | Plywood Case | Warranty: | 1 Year |
| Highlight: | Hydraulic System Components Piston Pumps,Hydraulic Transmission Principle Piston Pumps,Transmission Principle Hydraulic Piston Pumps |
||
Hydraulic Piston Pumps are high pressure pumps designed to deliver efficient and reliable performance in a variety of applications. With a rated pressure of 35Mpa, these pumps are perfect for heavy-duty tasks in the construction and agricultural industries.
The structure of these pumps is a variable displacement axial piston pump, which allows for a smooth and precise flow of hydraulic fluid. This results in improved control and accuracy in the operation of construction machinery, agricultural harvesters, and tractors.
As a type of hydraulic piston pump, our product is known for its durability, high efficiency, and excellent performance. It is built to withstand harsh working conditions and deliver consistent results, making it a popular choice among industries.
Our Hydraulic Piston Pumps are available for sale, catering to the needs of various industries. With its high pressure capabilities and variable displacement feature, it is suitable for a wide range of applications, providing superior performance and reliability.
To ensure the safe delivery of our product, we use standard export packaging - a sturdy plywood case. This guarantees that the pump remains in optimal condition during transportation, reducing the risk of any damage.
In summary, our Hydraulic Piston Pumps are high pressure pumps, with a variable displacement axial piston structure, suitable for construction machinery, agricultural harvesters, and tractors. With its superior performance, durability, and reliability, it is a top choice for industries looking for a high-quality piston pump for their operations.
| Product Name | Hydraulic Piston Pumps |
|---|---|
| Color | Black |
| Function | Hydraulic System Components |
| Principle | Hydraulic Transmission |
| Rated Pressure | 35Mpa |
| Hydraulic System | Closed Loop Axial Hydraulic Pump |
| Pressure Range | High Pressure |
| Standard Export Package | Plywood Case |
| Type | Hydraulic Piston Pump |
| Warranty | 1 Year |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
Hydraulic piston pumps usage:
a. Piston pumps are widely used in high-pressure, high-flow, high-power systems and occasions where the flow needs to be adjusted, such as agricultural machinery, construction machinery, mining and metallurgical machinery, and ships. It can play an important role.
b. Piston pumps are used in petroleum exploration and development, petrochemical, pharmaceutical, atomic energy science, environmental science, process equipment, experimental equipment, etc.
Tags: hydraulic system components, hydraulic transmission, hydraulic piston pump
