Product Details:
|
| Max.displacemen: | 110cc/r+110cc/r | Rated Pressure: | 350Bar Tandem Hydraulic Pump |
|---|---|---|---|
| Max Pressure: | 420Bar Tandem Hydraulic Pump | Material: | Cast Iron |
| Medium: | Hydraulic Oil | Warranty: | 1 Year |
| Function: | Hydraulic System Components | Package: | Plywood Case |
| Product Nam: | Discover The Versatility Of Tandem Hydraulic Pumps For Closed Circuit Systems | Rotation Direction: | Left Or Right |
| Highlight: | Versatility Hydraulic Pumps,Closed Circuit Systems Hydraulic Pumps,Versatility Tandem Hydraulic Pumps |
||
Discover the Versatility of Tandem Hydraulic Pumps for Closed Circuit Systems
Tandem hydraulic pumps basic information:
Step into the future of hydraulic systems with our advanced tandem hydraulic pumps, designed to redefine efficiency and performance across multiple industries. Our latest research explores the cutting-edge technology behind these pumps, revealing how their coordinated operation can achieve significant energy savings while ensuring consistent power delivery. Ideal for applications requiring robust hydraulic support, our pumps stand out as a key component for any forward-thinking enterprise seeking to enhance system efficiency and productivity.
Tandem hydraulic pumps main features:
Variable displacement axial piston pumps
Swash plate structure design
Closed circuit hydraulic system applications
Wide range of displacement
CW or CCW, left or right rotation direction
Compact structure
High efficiency, high pressure
Multiple control modes
Cutom manufacturing and design
Tandem hydraulic pumps technical specification:
| HPV hydraulic pump and HMF hydraulic motor series | ||||||||
| Displacement | Max displacement | ml/r | 110+110 | |||||
| Speed | Max continuous working speed (Full load condition) |
r/min | 2900 | |||||
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 535.3 | |||||
| Max output torque | Nm | 749 | ||||||
| Power | Continuous output power | KW | 149 | |||||
| Max power | KW | 173 | ||||||
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| weight | HPV series hydraulic pump hydraulic oil drain | kg | 164 | |||||
Highland company service for tandem hydrauilc pumps:
Quality service
One to one service, can provide design and installation solutions;
Online service for quick response and consultation;
Solve difficult after-sales problems;
Lightning supply
Regular single product supply for immediate delivery, batch can be quickly shipped according to customer demand;
Commitment to warranty tandem hydraulic pump within one year;
Provide personalized and customized services according to customer needs;
Notices:
Maintaining a balanced pressure load across tandem hydraulic pumps is essential to prevent system overloads and potential damage. In demanding environments like construction and earthmoving, where hydraulic systems face variable loads, an imbalance can cause one pump to overwork, leading to premature failure. Implementing pressure sensors and control systems that distribute work evenly between pumps can help in safeguarding against these risks, ensuring a durable and reliable hydraulic system.
Hydraulic oil notice of tandem hydraulic pumps:
Understanding the Operating Parameters: Tandem Hydraulic Pumps are complex devices that offer multiple flow rates and pressures. Before using, it's crucial to understand the operating parameters of each pump within the tandem setup. Operating beyond these specifications can result in decreased efficiency, increased wear, and potential pump failure.
FAQ of tandem hydraulic pumps:
Q1, Are you a factory or trading company?
A: We are a factory integrating research, development, production and sales.
Q2, What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3, How about your delivery time?
A: Generally, it will take 7 to 10 days after receiving your advance payment. The specific delivery time depends on the model and
the quantity of your order.
Q4, How can I get the new price of a product?
A: Please provide the exact or approximate quantity, packing details, destination port or special requirements, so we could give
you the price accordingly.
Q5, How do you make a price offer and how long is its validity?
A: We usually quote within 24 hours by email after we get your inquiry .If you are very urgent to get the price,please call us or
tell us in your email so that we will regard your inquiry priority. The price valid within 7 days.
Q6, Do you accept small order or Sample order?
A: Yes, we also accept sample order.
Q7, Do you accept third party inspection?
A: Yes, we do.
Q8, Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
Q9, How do you make our business long-term and good relationship?
A: 1. We keep good quality and competitive price to ensure our customers benefit.
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter.
