Product Details:
|
| Product Name: | Hydraulic Piston Pumps | Hydraulic System: | Closed Loop Axial Hydraulic Pump |
|---|---|---|---|
| Application: | Construction Machinery, Agricultural Harvester And Tractor | Package: | Plywood Case |
| Material: | Cast Iron | Function: | Hydraulic System Components |
| Rated Pressure: | 35Mpa | Max Pressure: | 42Mpa |
Our hydraulic piston pump is a closed loop axial hydraulic pump that is designed to deliver maximum performance in the toughest environments. With a strong and sturdy construction, this pump can withstand high pressure and extreme temperatures, making it ideal for heavy duty applications. It is also very versatile and can be used in a variety of hydraulic systems, ensuring that you get the best possible performance out of your equipment.
In addition to its impressive performance, our hydraulic piston pump is also very easy to install and use. With a simple and straightforward design, this pump can be quickly and easily integrated into your existing hydraulic system, minimizing downtime and maximizing productivity.
Our hydraulic piston pump comes in a standard export package, which includes a sturdy plywood case that ensures safe and secure transportation of your pump. The package is designed to protect your pump from damage during shipping, ensuring that it arrives at your location in perfect condition.
Our hydraulic piston pump is available in a sleek and stylish black color, which not only looks great but also helps to protect against corrosion and other forms of damage. This makes it an ideal choice for use in harsh environments where corrosion and other forms of damage are a concern.
Overall, if you are looking for a high quality hydraulic pump that can deliver reliable performance, exceptional efficiency, and exceptional durability, our hydraulic piston pump is the perfect choice. So why wait? Invest in one of our hydraulic piston pumps today and experience the ultimate in hydraulic performance!
| Technical Parameter | Description |
|---|---|
| Pressure Range | High Pressure |
| Type | Hydraulic Piston Pump |
| Application | Construction Machinery, Agricultural Harvester And Tractor |
| Principle | Hydraulic Transmission |
| Max Pressure | 42Mpa |
| Structure | Variable Displacement Axial Piston Pump |
| Hydraulic System | Closed Loop Axial Hydraulic Pump |
| Warranty | 1 Year |
| Standard Export Package | Plywood Case |
| Material | Cast Iron |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
The HPV110 model is a closed loop axial hydraulic pump that can withstand a rated pressure of 35Mpa. It is a high-pressure piston pump that can deliver excellent performance in various industries. This product is perfect for use in construction machinery, agricultural harvesters, and tractors.
With a minimum order quantity of 5 sets and a price range of USD900-1400/set, the HIGHLAND HPV110 Hydraulic Piston Pumps are an excellent investment for companies looking to improve their hydraulic systems. The supply ability of this product is 200 sets/month, ensuring that customers can receive their orders promptly.
The standard export package for this product is a plywood case, which ensures that the hydraulic piston pump is protected during transportation. The delivery time for this product is 10 working days, and customers can choose to pay through T/T or Western Union.
In summary, the HIGHLAND HPV110 Hydraulic Piston Pumps are a high-quality hydraulic pump that is ideal for use in various application occasions and scenarios. Its high-pressure piston pump and closed loop axial hydraulic pump make it a reliable and efficient product that can help increase productivity. With its certification, minimum order quantity, and supply ability, this product is an excellent investment for companies looking to improve their hydraulic systems.
Our services include:
Our team of experienced technicians and engineers are available to provide on-site support and assistance, as well as remote support via phone or email. We also offer customized service agreements to meet the specific needs of our customers.
At Hydraulic Piston Pumps, we are committed to providing the highest level of support and service to ensure that our customers' operations run smoothly and efficiently.
Q: What is the brand name of the Hydraulic Piston Pumps?
A: The brand name of the Hydraulic Piston Pumps is HIGHLAND.
Q: What is the model number of the Hydraulic Piston Pumps?
A: The model number of the Hydraulic Piston Pumps is HPV110.
Q: Where is the place of origin of the Hydraulic Piston Pumps?
A: The place of origin of the Hydraulic Piston Pumps is CHINA DEZHOU.
Q: Does the Hydraulic Piston Pumps have any certification?
A: Yes, the Hydraulic Piston Pumps has a PATENT CERTIFICATE.
Q: What is the price range of the Hydraulic Piston Pumps?
A: The price range of the Hydraulic Piston Pumps is USD900-1400 per set.
Q: What is the minimum order quantity for the Hydraulic Piston Pumps?
A: The minimum order quantity for the Hydraulic Piston Pumps is 5 sets.
Q: What are the packaging details for the Hydraulic Piston Pumps?
A: The packaging details for the Hydraulic Piston Pumps is Plywood Case.
Q: What is the delivery time for the Hydraulic Piston Pumps?
A: The delivery time for the Hydraulic Piston Pumps is 10 working days.
Q: What are the payment terms for the Hydraulic Piston Pumps?
A: The payment terms for the Hydraulic Piston Pumps are T/T and Western Union.
Q: What is the supply ability for the Hydraulic Piston Pumps?
A: The supply ability for the Hydraulic Piston Pumps is 200 sets per month.
Tags: closed loop hydraulic piston pump, 42Mpa high pressure hydraulic pump, hydraulic pump for hydraulic system
