Product Details:
|
| Pressure Range: | High Pressure | Max Pressure: | 42Mpa |
|---|---|---|---|
| Structure: | Variable Displacement Axial Piston Pump | Package: | Plywood Case |
| Application: | Construction Machinery, Agricultural Harvester And Tractor | Standard Export Package: | Plywood Case |
| Rated Pressure: | 35Mpa | Product Name: | Hydraulic Piston Pumps |
Our hydraulic piston pumps are designed for high pressure applications, making them a reliable choice for heavy duty machinery and equipment. With a range of sizes and specifications available, we have a hydraulic piston pump for sale that is perfect for your specific needs.
The design of this hydraulic piston pump ensures efficient and reliable performance, with a high level of precision and control. This makes it an ideal choice for a variety of hydraulic applications, including construction, manufacturing, and transportation.
Our hydraulic piston pump comes packaged in a sturdy plywood case, ensuring safe and secure transportation and storage. With its durable construction, high pressure capabilities, and efficient design, this hydraulic piston pump is a must-have for any hydraulic system.
This high quality hydraulic piston pump is perfect for a variety of applications, including industrial and construction use. With a pressure range of high pressure and a max pressure of 42Mpa, it is sure to meet your needs. This piston pump for sale is also known as the HPV110 hydraulic pump and comes in a standard export package of a plywood case.
| Product Name: | Hydraulic Piston Pump |
| Model: | HPV110 Hydraulic Pump |
| Package: | Plywood Case |
| Color: | Black |
| Pressure Range: | High Pressure |
| Warranty: | 1 Year |
| Material: | Cast Iron |
| Rated Pressure: | 35Mpa |
| Application: | Construction Machinery, Agricultural Harvester And Tractor |
| Power Source: | Hydraulic |
| Function: | Hydraulic System Components |
| Principle: | Hydraulic Transmission |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
Designed to withstand high pressure, the HIGHLAND HPV110 Hydraulic Piston Pumps are ideal for a wide range of applications. Its hydraulic transmission principle makes it suitable for various heavy-duty tasks that require precision and accuracy.
The HIGHLAND HPV110 Hydraulic Piston Pumps come in a sleek black color that adds a touch of elegance to any machine it is attached to. It can handle a maximum pressure of 42Mpa, making it a reliable choice for high-pressure applications.
Whether you're in the construction, manufacturing, or agricultural industry, the HIGHLAND HPV110 Hydraulic Piston Pumps will get the job done. It can be used for hydraulic systems, hydraulic presses, hydraulic power units, and other hydraulic equipment.
When it comes to packaging, the HIGHLAND HPV110 Hydraulic Piston Pumps are well-protected in a sturdy plywood case during transportation. You can expect your order to be delivered within 10 working days, and payment can be made through T/T or Western Union.
With a supply ability of 200 sets per month, the HIGHLAND HPV110 Hydraulic Piston Pumps are readily available whenever you need them.
Investing in the HIGHLAND HPV110 Hydraulic Piston Pumps means investing in a reliable and durable hydraulic pump that will exceed your expectations. Get your hands on the HIGHLAND HPV110 hydraulic pump today and experience its exceptional performance for yourself!
Our Hydraulic Piston Pumps are designed to provide high-pressure power for a variety of applications. We offer a range of sizes and configurations to meet your specific needs.
Our technical support team is always available to provide assistance with installation, operation, and maintenance of your hydraulic piston pump. We also offer repair and rebuilding services to extend the life of your pump and minimize downtime.
Our services include:
Q: What is the brand name of the hydraulic piston pump?
A: The brand name of the hydraulic piston pump is HIGHLAND.
Q: What is the model number of the hydraulic piston pump?
A: The model number of the hydraulic piston pump is HPV110.
Q: What is the place of origin of the hydraulic piston pump?
A: The hydraulic piston pump is manufactured in CHINA DEZHOU.
Q: Is the hydraulic piston pump certified?
A: Yes, the hydraulic piston pump has a PATENT CERTIFICATE.
Q: What is the minimum order quantity for the hydraulic piston pump?
A: The minimum order quantity for the hydraulic piston pump is 5 sets.
Q: What is the price range of the hydraulic piston pump?
A: The price range of the hydraulic piston pump is between USD 900 to USD 1400 per set.
Q: How is the hydraulic piston pump packaged for delivery?
A: The hydraulic piston pump is packaged in a Plywood Case.
Q: What is the delivery time for the hydraulic piston pump?
A: The delivery time for the hydraulic piston pump is 10 working days.
Q: What are the payment terms for the hydraulic piston pump?
A: The payment terms for the hydraulic piston pump are T/T and Western Union.
Q: What is the supply ability of the hydraulic piston pump?
A: The supply ability of the hydraulic piston pump is 200 sets per month.
