Product Details:
|
| Pressure Range: | High Pressure | Material: | Cast Iron |
|---|---|---|---|
| Hydraulic System: | Closed Loop Axial Hydraulic Pump | Max Pressure: | 42Mpa |
| Rated Pressure: | 35Mpa | Package: | Plywood Case |
| Function: | Hydraulic System Components | Type: | Hydraulic Piston Pump |
The Hydraulic Piston Pumps is known for its outstanding performance, making it a top choice for many industries. It is designed to operate under high pressure, with a maximum pressure of 42Mpa. This allows it to handle tough and demanding jobs with ease.
One of the best features of the Hydraulic Piston Pumps is its power source. It is a hydraulic pump, which means that it is powered by a hydraulic system. This makes it an ideal choice for heavy-duty applications where a lot of power is required. The HPV110 hydraulic pump is a piston pump for sale that is designed to deliver high performance and efficiency.
The Hydraulic Piston Pumps is a versatile product that can be used in many different industries. It is commonly used in construction, mining, agriculture, oil and gas, and manufacturing. It can be used for a wide range of applications, including powering hydraulic machinery, lifting heavy loads, and driving industrial equipment.
If you are looking for a high-quality hydraulic pump that can handle tough jobs, then the Hydraulic Piston Pumps is the right product for you. It is a reliable and efficient product that is designed to deliver outstanding performance. It is also easy to install and maintain, making it a convenient choice for many industries.
| Attribute | Value |
|---|---|
| Product Name | Hydraulic Piston Pumps |
| Type | Hydraulic Piston Pump |
| Power Source | Hydraulic |
| Principle | Hydraulic Transmission |
| Function | Hydraulic System Components |
| Hydraulic System | Closed Loop Axial Hydraulic Pump |
| Rated Pressure | 35Mpa |
| Application | Construction Machinery, Agricultural Harvester And Tractor |
| Package | Plywood Case |
| Standard Export Package | Plywood Case |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
With its variable displacement axial piston pump structure, the HPV110 is a top-of-the-line choice for any hydraulic system. It boasts a maximum pressure of 42Mpa and comes in a sleek black color.
Not only is the HPV110 a high-performing pump, it also comes with a PATENT CERTIFICATE for added peace of mind. And with a minimum order quantity of just 5 sets and a price range of USD900-1400 per set, it's an affordable choice for any budget.
When you order the HPV110, you can expect it to arrive in sturdy plywood packaging within just 10 working days. Plus, with payment options including T/T and Western Union, it's easy to complete your purchase.
And with a supply ability of 200 sets per month, you can rest assured that you'll always have access to the HPV110 when you need it. So why wait? Invest in the best hydraulic piston pump for sale and choose the HIGHLAND HPV110.
The Hydraulic Piston Pumps product technical support and services include the following:
- Assistance with product selection and sizing
- Installation guidance
- Troubleshooting and repair services
- Maintenance and service contracts
- Training and education programs
- Technical documentation and manuals
Q: What is the brand name of the Hydraulic Piston Pumps?
A: The brand name of the Hydraulic Piston Pumps is HIGHLAND.
Q: What is the model number of the Hydraulic Piston Pumps?
A: The model number of the Hydraulic Piston Pumps is HPV110.
Q: Where are the Hydraulic Piston Pumps made?
A: The Hydraulic Piston Pumps are made in China, specifically in Dezhou.
Q: What is the certification of the Hydraulic Piston Pumps?
A: The Hydraulic Piston Pumps have a patent certificate.
Q: What is the minimum order quantity for the Hydraulic Piston Pumps?
A: The minimum order quantity for the Hydraulic Piston Pumps is 5 sets.
Q: What is the price range for the Hydraulic Piston Pumps?
A: The price range for the Hydraulic Piston Pumps is between USD900-1400 per set.
Q: What are the packaging details for the Hydraulic Piston Pumps?
A: The Hydraulic Piston Pumps are packaged in plywood cases.
Q: What is the delivery time for the Hydraulic Piston Pumps?
A: The delivery time for the Hydraulic Piston Pumps is 10 working days.
Q: What are the payment terms for the Hydraulic Piston Pumps?
A: The payment terms for the Hydraulic Piston Pumps are T/T and Western Union.
Q: What is the supply ability for the Hydraulic Piston Pumps?
A: The supply ability for the Hydraulic Piston Pumps is 200 sets per month.
