Product Details:
|
| Hydraulic System: | Closed Loop Axial Hydraulic Pump | Rated Pressure: | 35Mpa |
|---|---|---|---|
| Application: | Construction Machinery, Agricultural Harvester And Tractor | Warranty: | 1 Year |
| Product Name: | Hydraulic Piston Pumps | Material: | Cast Iron |
| Pressure Range: | High Pressure | Structure: | Variable Displacement Axial Piston Pump |
Our hydraulic piston pump is specifically designed for use in hydraulic systems, making it an essential component for those in need of reliable and efficient hydraulic power. With its closed loop design, our hydraulic piston pump is able to deliver consistent and precise hydraulic power, ensuring that your hydraulic system runs smoothly and efficiently at all times.
Whether you're in need of a piston pump for sale for your industrial or agricultural needs, our hydraulic piston pump is the perfect choice. With its high pressure capabilities, our piston pump is able to handle even the toughest hydraulic applications with ease, making it the ideal choice for those in need of a powerful and reliable hydraulic pump.
At our company, we stand behind the quality and durability of our hydraulic piston pump, which is why we offer a 1-year warranty on all of our products. So if you're in need of a high-quality hydraulic piston pump for sale, look no further than our top-of-the-line hydraulic piston pump!
So why wait? Contact us today to learn more about our hydraulic piston pump and to place your order. With our unbeatable quality, reliability, and affordability, our hydraulic piston pump is the perfect choice for those seeking a top-of-the-line hydraulic pump for their hydraulic system.
Looking for a high quality hydraulic pump? Check out our piston pump for sale! Our HPV110 hydraulic pump is perfect for construction machinery, agricultural harvesters, and tractors. Plus, with a 1 year warranty, you can trust that you're getting a reliable product.
| Product Name | Hydraulic Piston Pumps |
| Material | Cast Iron |
| Hydraulic System | Closed Loop Axial Hydraulic Pump |
| Principle | Hydraulic Transmission |
| Function | Hydraulic System Components |
| Warranty | 1 Year |
| Color | Black |
| Standard Export Package | Plywood Case |
| Rated Pressure | 35Mpa |
| Max Pressure | 42Mpa |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
The HPV110 hydraulic pump is a hydraulic transmission system component that is used in various applications. Its power source is hydraulic, and it is designed with a principle of hydraulic transmission. The product is suitable for use in construction machinery, agricultural harvesters, and tractors.
The HPV110 hydraulic piston pump is a reliable product that is suitable for heavy-duty applications. It is designed to provide high-pressure output, making it ideal for use in hydraulic systems that require high-pressure fluid delivery. The product is packaged in a standard export package, which is a plywood case. The delivery time for this product is 10 working days, and the payment terms are T/T or Western Union.
The HIGHLAND HPV110 hydraulic piston pump is a versatile product that can be used in various scenarios. Its high-pressure output makes it suitable for use in hydraulic systems that require high-pressure fluid delivery. The product is suitable for use in construction machinery, such as excavators and bulldozers, as well as in agricultural machinery, such as harvesters and tractors.
The HPV110 hydraulic piston pump is a reliable and durable product that is designed to withstand heavy-duty use. Its unique design, as evidenced by its patent certificate, ensures that it is a high-quality product that performs optimally. The product has a supply ability of 200 sets per month, which means that it is readily available for purchase.
The Hydraulic Piston Pumps product is designed to provide high pressure and high efficiency fluid power for a wide range of industrial applications. Our team of technical experts is available to provide product support and services to ensure optimal performance and longevity of your pump. Our support services include:
Our technical support team is committed to providing exceptional customer service and timely assistance for any issues or questions related to our Hydraulic Piston Pumps. Contact us for more information on how we can assist you.
Q: What is the brand of the hydraulic piston pump?
A: The brand of the hydraulic piston pump is HIGHLAND.
Q: What is the model number of the hydraulic piston pump?
A: The model number of the hydraulic piston pump is HPV110.
Q: Where is the hydraulic piston pump manufactured?
A: The hydraulic piston pump is manufactured in CHINA DEZHOU.
Q: What certification does the hydraulic piston pump have?
A: The hydraulic piston pump has a PATENT CERTIFICATE.
Q: What is the minimum order quantity for the hydraulic piston pump?
A: The minimum order quantity for the hydraulic piston pump is 5 sets.
Q: What is the price range of the hydraulic piston pump?
A: The price range of the hydraulic piston pump is USD900-1400/set.
Q: What are the packaging details for the hydraulic piston pump?
A: The packaging details for the hydraulic piston pump are Plywood Case.
Q: What is the delivery time for the hydraulic piston pump?
A: The delivery time for the hydraulic piston pump is 10 working days.
Q: What are the payment terms for the hydraulic piston pump?
A: The payment terms for the hydraulic piston pump are T/T, Western Union.
Q: What is the supply ability for the hydraulic piston pump?
A: The supply ability for the hydraulic piston pump is 200 sets/month.
Tags: variable displacement piston pump, 35Mpa rated pressure hydraulic pump, axial piston pump
