Product Details:
|
| Structure: | Variable Displacement Axial Piston Pump | Function: | Hydraulic System Components |
|---|---|---|---|
| Warranty: | 1 Year | Package: | Plywood Case |
| Color: | Black | Rated Pressure: | 35Mpa |
| Application: | Construction Machinery, Agricultural Harvester And Tractor | Standard Export Package: | Plywood Case |
The Variable Displacement Axial Piston Pump is designed as a closed loop axial hydraulic pump, making it ideal for hydraulic systems that require high pressure and flow rates. It is a versatile pump that can be used for a variety of applications, including industrial machinery, construction equipment, and agricultural machinery.
Our hydraulic piston pump is known for its exceptional quality and performance. It is designed to deliver consistent and reliable performance, even in the most demanding environments. The Variable Displacement Axial Piston Pump is a powerful and efficient pump that can handle large volumes of fluid with ease.
When you purchase our hydraulic pump, you can be confident that you are getting a top-quality product that is built to last. We stand behind the quality of our products and offer a 1-year warranty on all of our hydraulic piston pumps.
In summary, if you are looking for a high quality hydraulic pump that is built to last, look no further than our Variable Displacement Axial Piston Pump. With its cast iron construction, closed loop axial hydraulic design, and reliable performance, this pump is the perfect choice for a wide range of hydraulic applications.
| Product Name: | Hydraulic Piston Pumps |
| Type: | Hydraulic Piston Pump |
| Max Pressure: | 42Mpa |
| Hydraulic System: | Closed Loop Axial Hydraulic Pump |
| Function: | Hydraulic System Components |
| Structure: | Variable Displacement Axial Piston Pump |
| Material: | Cast Iron |
| Standard Export Package: | Plywood Case |
| Package: | Plywood Case |
| Principle: | Hydraulic Transmission |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
The HPV110 hydraulic piston pump is designed to be used in a variety of scenarios. Its high pressure capabilities make it ideal for heavy duty industrial machinery, such as hydraulic presses, cranes, and excavators. The pump's variable displacement also makes it suitable for applications that require precise control over the flow of hydraulic fluid, such as in injection molding machines and hydraulic power units.
The HIGHLAND HPV110 hydraulic piston pump is a patented product, and comes with a patent certificate. The minimum order quantity for this product is 5 sets, with a price range of USD900-1400 per set. The pump is packaged in a plywood case for safe transportation, and has a delivery time of 10 working days.
When it comes to payment, HIGHLAND accepts T/T and Western Union. They also have a supply ability of 200 sets per month, ensuring that customers can receive their orders in a timely manner. The standard export package for the HPV110 hydraulic piston pump is a plywood case, ensuring that the product arrives at its destination in the same condition it left the factory.
In summary, the HIGHLAND HPV110 hydraulic piston pump is a high quality hydraulic pump that is suitable for a wide range of industrial applications. Its variable displacement and high pressure capabilities make it ideal for heavy duty machinery, while its precise control over hydraulic fluid flow makes it suitable for more specialized applications. With a patent certificate, reliable packaging, and a variety of payment options, HIGHLAND provides customers with a reliable and efficient product that meets all their hydraulic pump needs.
Our Hydraulic Piston Pumps product line is designed to provide reliable and efficient performance for a wide range of industrial applications. We offer a variety of models with different flow rates, pressure ratings, and configurations to meet your specific needs.
Our team of experienced technical support specialists is available to assist you with any questions or issues you may have with our Hydraulic Piston Pumps. We offer comprehensive product training and troubleshooting assistance to ensure that you are getting the most out of your equipment.
In addition to our technical support services, we also provide a range of maintenance and repair services to keep your Hydraulic Piston Pumps operating at peak performance. Our certified technicians can perform on-site repairs or provide replacement parts as needed to minimize downtime and maximize productivity.
1. What is the brand name of the hydraulic piston pump?
The brand name of the hydraulic piston pump is HIGHLAND.
2. What is the model number of the hydraulic piston pump?
The model number of the hydraulic piston pump is HPV110.
3. Where is the hydraulic piston pump manufactured?
The hydraulic piston pump is manufactured in China Dezhou.
4. Is the hydraulic piston pump certified?
Yes, the hydraulic piston pump is certified with a patent certificate.
5. What is the minimum order quantity and price of the hydraulic piston pump?
The minimum order quantity for the hydraulic piston pump is 5 sets and the price ranges from USD900-1400 per set.
6. What are the packaging details and delivery time of the hydraulic piston pump?
The packaging details for the hydraulic piston pump are plywood case and the delivery time is 10 working days.
7. What are the payment terms and supply ability of the hydraulic piston pump?
The payment terms for the hydraulic piston pump are T/T and Western Union. The supply ability is 200 sets per month.
