Product Details:
|
| Principle: | Hydraulic Transmission | Rated Pressure: | 35Mpa |
|---|---|---|---|
| Material: | Cast Iron | Hydraulic System: | Closed Loop Axial Hydraulic Pump |
| Max Pressure: | 42Mpa | Function: | Hydraulic System Components |
| Warranty: | 1 Year | Product Name: | Hydraulic Piston Pumps |
With a maximum pressure of 42Mpa, this piston pump for sale is capable of delivering exceptional power and performance, even in high-pressure hydraulic systems. Whether you need to power heavy machinery, hydraulic presses, or other demanding applications, the HPV110 can deliver the reliable performance you need to get the job done.
One of the key features of this hydraulic piston pump is its closed loop axial hydraulic system, which enables precise control over fluid flow and pressure. This system ensures that the HPV110 can deliver consistent performance, even in varying load conditions, which makes it an ideal choice for a wide range of industrial applications.
Another important attribute of the HPV110 is its variable displacement design, which allows it to adjust fluid flow and pressure to match the specific needs of your hydraulic system. This means that you can use this piston pump to power a range of different applications, without having to worry about compatibility issues or performance limitations.
When you purchase the HPV110 piston pump for sale, you can expect to receive it in a sturdy plywood case that will protect it during shipping and storage. This package is designed to ensure that your pump arrives in excellent condition and is ready for use right out of the box.
So if you're looking for a high pressure piston pump that can deliver exceptional performance and reliability for your hydraulic system, look no further than the HPV110 hydraulic pump. With its closed loop axial hydraulic system, variable displacement design, and maximum pressure of 42Mpa, this piston pump is the ideal choice for a wide range of industrial applications.
| Product Name | HPV110 Hydraulic Piston Pump |
| Structure | Variable Displacement Axial Piston Pump |
| Application | Construction Machinery, Agricultural Harvester And Tractor |
| Standard Export Package | Plywood Case |
| Function | Hydraulic System Components |
| Warranty | 1 Year |
| Color | Black |
| Material | Cast Iron |
| Principle | Hydraulic Transmission |
| Pressure Range | High Pressure |
| Power Source | Hydraulic |
| Buy | Piston Pump for Sale |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
The HPV110 hydraulic pump is a closed loop axial hydraulic pump, providing a reliable and efficient power source for hydraulic systems. Its variable displacement axial piston pump structure allows for flexible and precise control of the hydraulic system, making it suitable for a wide range of occasions and scenarios.
One of the main applications of the HIGHLAND HPV110 hydraulic piston pump is in heavy machinery and equipment, such as excavators, loaders, and bulldozers. These machines require a high pressure piston pump to power their hydraulic systems, and the HPV110 is a perfect fit for this purpose.
In addition to heavy machinery, the HPV110 hydraulic pump can also be used in other industrial applications, such as manufacturing, construction, and transportation. Its reliable and efficient performance makes it a popular choice for these industries.
The HIGHLAND HPV110 hydraulic piston pump comes packaged in a sturdy plywood case, ensuring that it is protected during transit. The delivery time for this product is 10 working days, and payment can be made via T/T or Western Union.
With a supply ability of 200 sets per month, the HIGHLAND HPV110 hydraulic piston pump is readily available for all your hydraulic system needs. Whether you need a power source for heavy machinery or industrial equipment, the HPV110 is a dependable and efficient choice.
Our Hydraulic Piston Pumps are designed for high-performance and reliable operation. We offer a range of technical support and services to ensure maximum uptime and productivity for your equipment:
Our team of experienced technicians is dedicated to providing exceptional service and support to help you get the most out of your Hydraulic Piston Pump. Contact us for more information on our technical support and services.
Q: What is the brand name of this hydraulic piston pump?
A: The brand name of this hydraulic piston pump is HIGHLAND.
Q: What is the model number of this hydraulic piston pump?
A: The model number of this hydraulic piston pump is HPV110.
Q: Where is this hydraulic piston pump made?
A: This hydraulic piston pump is made in CHINA DEZHOU.
Q: Does this hydraulic piston pump come with any certifications?
A: Yes, this hydraulic piston pump comes with a PATENT CERTIFICATE.
Q: What is the minimum order quantity for this hydraulic piston pump?
A: The minimum order quantity for this hydraulic piston pump is 5 sets.
Q: What is the price range for this hydraulic piston pump?
A: The price range for this hydraulic piston pump is USD900-1400 per set.
Q: What is the packaging detail for this hydraulic piston pump?
A: The packaging detail for this hydraulic piston pump is Plywood Case.
Q: What is the delivery time for this hydraulic piston pump?
A: The delivery time for this hydraulic piston pump is 10 working days.
Q: What are the payment terms for this hydraulic piston pump?
A: The payment terms for this hydraulic piston pump are T/T and Western Union.
Q: What is the supply ability for this hydraulic piston pump?
A: The supply ability for this hydraulic piston pump is 200 sets per month.
