Product Details:
|
| Function: | Hydraulic System Components | Rated Pressure: | 35Mpa |
|---|---|---|---|
| Application: | Construction Machinery, Agricultural Harvester And Tractor | Product Name: | Hydraulic Piston Pumps |
| Pressure Range: | High Pressure | Color: | Black |
| Hydraulic System: | Closed Loop Axial Hydraulic Pump | Max Pressure: | 42Mpa |
The black color of the pump not only adds a sleek and professional look to your machinery, but it also helps to protect the pump from external wear and tear. Its high-pressure capabilities make it ideal for heavy-duty applications such as construction equipment, mining machinery, and agricultural machinery.
Our hydraulic piston pump is designed with precision to ensure maximum efficiency with minimal noise and vibration. Its compact size allows for easy installation and maintenance, making it a popular choice among professionals in the hydraulic industry.
Whether you're pumping oil, water, or other fluids, the HPV110 hydraulic pump can handle it all with ease. Its reliable performance and durability ensure that you can rely on this high-pressure piston pump for years to come.
Investing in our hydraulic piston pump will not only improve the efficiency and performance of your hydraulic system, but it will also save you time and money in the long run. Its high quality and reliable performance make it a popular choice among professionals in the hydraulic industry.
| Attribute | Value |
|---|---|
| Product Name | Hydraulic Piston Pumps |
| Material | Cast Iron |
| Package | Plywood Case |
| Standard Export Package | Plywood Case |
| Pressure Range | High Pressure |
| Max Pressure | 42Mpa |
| Type | Hydraulic Piston Pump |
| Structure | Variable Displacement Axial Piston Pump |
| Principle | Hydraulic Transmission |
| Power Source | Hydraulic |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
Whether you need a piston pump for sale for use in construction, mining, agriculture, or any other industry that requires powerful and precise hydraulic machinery, the HIGHLAND HPV110 is an excellent choice. It boasts a pressure range that can handle even the toughest jobs, and its cast iron construction ensures durability and longevity.
Ordering from us is easy and convenient. We require a minimum order quantity of just 5 sets, and our prices range from USD900-1400 per set. Our standard export package is a sturdy plywood case, and we can typically deliver your order within 10 working days. We accept payment via T/T or Western Union, and our supply ability is 200 sets per month.
Don't settle for a subpar hydraulic pump that can't meet your needs. Choose the HIGHLAND HPV110 and enjoy reliable, high-performing machinery that will help you get the job done right.
Our Hydraulic Piston Pumps are designed to provide reliable and efficient power for a variety of industrial applications. We offer a range of pumps with different flow rates and pressure capabilities to meet the specific needs of our customers.
Our team of technical support specialists is available to assist with any questions or issues related to our Hydraulic Piston Pumps. We provide in-depth product training and troubleshooting assistance to ensure that our customers can operate their pumps at peak performance.
In addition to technical support, we also offer a variety of services to keep our Hydraulic Piston Pumps running smoothly. Our maintenance and repair services include routine inspections, parts replacement, and on-site repairs. We are committed to providing fast and efficient service to minimize downtime for our customers.
At our company, we prioritize customer satisfaction and strive to exceed expectations with every interaction. Contact us today to learn more about our Hydraulic Piston Pumps and the services we offer.
Q: What is the brand name of this hydraulic piston pump?
A: The brand name of this hydraulic piston pump is HIGHLAND.
Q: What is the model number of this hydraulic piston pump?
A: The model number of this hydraulic piston pump is HPV110.
Q: Where is this hydraulic piston pump manufactured?
A: This hydraulic piston pump is manufactured in CHINA DEZHOU.
Q: Does this hydraulic piston pump come with any certifications?
A: Yes, this hydraulic piston pump comes with a PATENT CERTIFICATE.
Q: What is the minimum order quantity for this hydraulic piston pump?
A: The minimum order quantity for this hydraulic piston pump is 5 sets.
Q: What is the price of this hydraulic piston pump?
A: The price of this hydraulic piston pump ranges from USD900-1400 per set.
Q: What are the packaging details for this hydraulic piston pump?
A: The packaging details for this hydraulic piston pump are Plywood Case.
Q: What is the delivery time for this hydraulic piston pump?
A: The delivery time for this hydraulic piston pump is 10 working days.
Q: What are the payment terms for this hydraulic piston pump?
A: The payment terms for this hydraulic piston pump are T/T and Western Union.
Q: What is the supply ability for this hydraulic piston pump?
A: The supply ability for this hydraulic piston pump is 200 sets per month.
Tags: Closed loop axial piston pump, HPV110 hydraulic pump, piston pump for sale
