Product Details:
|
| Product Name: | Hydraulic Piston Pumps | Material: | Cast Iron |
|---|---|---|---|
| Structure: | Variable Displacement Axial Piston Pump | Standard Export Package: | Plywood Case |
| Power Source: | Hydraulic | Warranty: | 1 Year |
| Pressure Range: | High Pressure | Max Pressure: | 42Mpa |
| Highlight: | Cast Iron Piston Pump,High Pressure Piston Pump,42mpa Piston Pump |
||
With a pressure range of up to 42Mpa, the HPV110 hydraulic pump can handle even the toughest hydraulic tasks. Its hydraulic transmission principle ensures smooth and precise operation, making it the perfect choice for any hydraulic system that requires high-pressure performance.
Our HPV110 hydraulic pump is a reliable power source that can handle a variety of hydraulic applications. Whether you need to power a hydraulic press, a hydraulic motor, or any other hydraulic equipment, the HPV110 hydraulic pump is up to the task.
Our high-quality hydraulic pump is built to last, with durable materials and careful attention to detail. We take pride in our products, and we stand behind them with a commitment to quality and customer satisfaction.
So if you're looking for a high-pressure piston pump for your hydraulic system, look no further than the HPV110 hydraulic pump. With its reliable performance, efficient design, and durable construction, it's the perfect choice for any hydraulic application.
This hydraulic piston pump is a must-have component for any hydraulic system. It is designed to provide reliable and efficient performance, making it an ideal choice for a wide range of applications. Whether you're looking for a piston pump for sale or need a reliable hydraulic component for your industrial machinery, this hydraulic piston pump is the perfect choice.
| Material: | Cast Iron |
| Max Pressure: | 42Mpa |
| Pressure Range: | High Pressure |
| Warranty: | 1 Year |
| Structure: | Variable Displacement Axial Piston Pump |
| Hydraulic System: | Closed Loop Axial Hydraulic Pump |
| Package: | Plywood Case |
| Color: | Black |
| Product Name: | Hydraulic Piston Pumps |
| Application: | Construction Machinery, Agricultural Harvester And Tractor |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
The HPV110 hydraulic pump is widely used in various industrial applications. It is ideal for heavy-duty machinery that requires a reliable and efficient hydraulic system. This piston pump for sale is perfect for construction machinery, such as excavators, bulldozers, and loaders. It is also used in agricultural machinery, such as tractors and harvesters. The closed-loop axial hydraulic pump is suitable for applications that require high precision and accuracy. The hydraulic system of the HPV110 hydraulic pump is designed to provide a consistent and reliable performance, making it an ideal choice for demanding applications.
The HPV110 hydraulic pump is a hydraulic piston pump that is powered by hydraulic pressure. It is a type of positive displacement pump that is designed to deliver high-pressure fluid flow. This hydraulic pump is suitable for applications that require a high flow rate and high-pressure output. It is designed to operate in a closed-loop hydraulic system, which provides greater efficiency and reliability. The hydraulic system of the HPV110 hydraulic pump is designed to provide a consistent and reliable performance, making it an ideal choice for demanding applications.
The HPV110 hydraulic pump is an excellent choice for those looking for a reliable and efficient hydraulic piston pump for sale. Its high-quality construction and reliable performance make it an ideal choice for a wide range of applications. So, if you are in the market for a high-quality hydraulic piston pump, look no further than the HPV110 hydraulic pump from HIGHLAND.
Our Hydraulic Piston Pumps are designed and manufactured to provide reliable and efficient performance in a variety of applications. We offer product technical support and services to ensure our customers get the most out of their hydraulic systems.
Our technical support team is available to answer any questions or concerns regarding the installation, operation, and maintenance of our hydraulic piston pumps. We also offer troubleshooting assistance and can provide guidance on proper system design and selection of components.
In addition, our services include repair and refurbishment of hydraulic piston pumps to extend their lifespan and minimize downtime. We use only genuine replacement parts and our technicians are highly skilled and trained to ensure quality workmanship.
Q1: What is the brand name of the hydraulic piston pump?
A1: The brand name of the hydraulic piston pump is HIGHLAND.
Q2: What is the model number of the hydraulic piston pump?
A2: The model number of the hydraulic piston pump is HPV110.
Q3: Where is the hydraulic piston pump manufactured?
A3: The hydraulic piston pump is manufactured in CHINA DEZHOU.
Q4: Is the hydraulic piston pump certified?
A4: Yes, the hydraulic piston pump has a PATENT CERTIFICATE.
Q5: What is the minimum order quantity for the hydraulic piston pump?
A5: The minimum order quantity for the hydraulic piston pump is 5 sets.
Q6: What is the price range for the hydraulic piston pump?
A6: The price range for the hydraulic piston pump is USD900-1400 per set.
Q7: What is the packaging method for the hydraulic piston pump?
A7: The hydraulic piston pump is packaged in a Plywood Case.
Q8: What is the delivery time for the hydraulic piston pump?
A8: The delivery time for the hydraulic piston pump is 10 working days.
Q9: What are the payment terms for the hydraulic piston pump?
A9: The payment terms for the hydraulic piston pump are T/T and Western Union.
Q10: What is the supply ability for the hydraulic piston pump?
A10: The supply ability for the hydraulic piston pump is 200 sets per month.
