Product Details:
|
| Hydraulic System: | Closed Loop Axial Hydraulic Pump | Power Source: | Hydraulic |
|---|---|---|---|
| Material: | Cast Iron | Product Name: | Hydraulic Piston Pumps |
| Type: | Hydraulic Piston Pump | Function: | Hydraulic System Components |
| Rated Pressure: | 35Mpa | Color: | Black |
| Highlight: | Cast Iron Hydraulic Piston Pump,35Mpa Hydraulic Piston Pump,Closed Loop Hydraulic Piston Pump |
||
Our Hydraulic Piston Pump is designed with a maximum pressure of 42Mpa, making it a high pressure piston pump capable of withstanding even the toughest of applications. Its sturdy construction ensures durability and longevity, giving you peace of mind knowing that this hydraulic pump will withstand the test of time.
Our Hydraulic Piston Pump is an essential component of any hydraulic system. Its variable displacement design ensures that your hydraulic system is running at optimal performance, allowing you to get the most out of your equipment. With its high efficiency and low noise output, this hydraulic piston pump is the perfect addition to any hydraulic system.
Our Hydraulic Piston Pump comes packaged in a standard export package, ensuring that it arrives at your location safely and securely. The plywood case protects the pump from any damage during transport, giving you the confidence that your pump will arrive in perfect condition.
At Highland hydraulic, we take pride in providing our customers with high quality hydraulic pumps at an affordable price. Our Hydraulic Piston Pump is no exception, offering you the best value for your money. Whether you are in need of a replacement pump or are looking to upgrade your existing system, our Hydraulic Piston Pump is the perfect choice.
| Product Attribute | Description |
|---|---|
| Product Name | HPV110 hydraulic pump |
| Function | Hydraulic System Components |
| Hydraulic System | Closed Loop Axial Hydraulic Pump |
| Standard Export Package | Plywood Case |
| Max Pressure | 42Mpa |
| Application | Construction Machinery, Agricultural Harvester And Tractor |
| Power Source | Hydraulic |
| Color | Black |
| Material | Cast Iron |
| Rated Pressure | 35Mpa |
| Package | Plywood Case |
| Additional Keywords | piston pump for sale, High quality hydraulic pump |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
With a rated pressure of 35Mpa and a variable displacement axial piston pump structure, the HIGHLAND HPV110 is capable of delivering high levels of power and performance in a compact and reliable package. Whether you are looking for a hydraulic pump for a mobile or stationary application, this pump is an excellent choice.
Designed and manufactured in CHINA DEZHOU, this hydraulic piston pump is built to the highest standards of quality and reliability. It comes with a patent certificate, providing assurance that you are getting a high quality product that has been tested and approved for use in demanding applications.
The HIGHLAND HPV110 hydraulic piston pump is suitable for use in a wide range of hydraulic systems, including closed loop axial hydraulic pump systems. It is an ideal choice for applications where high pressure and high performance are required, such as in construction, mining, and other heavy-duty industries.
With a minimum order quantity of just 5 sets, this hydraulic piston pump is an affordable and reliable choice for businesses of all sizes. The price for each set ranges from USD900-1400/Set, making it a cost-effective option for those looking for a high quality hydraulic pump.
The packaging details for the HIGHLAND HPV110 hydraulic piston pump include a plywood case, providing protection during shipping and storage. Delivery time is typically around 10 working days, and payment terms include T/T and Western Union.
With a supply ability of 200 sets per month, the HIGHLAND HPV110 hydraulic piston pump is readily available for those in need of a high quality hydraulic pump. Made from cast iron, this pump is built to last and provides reliable performance in even the most demanding applications.
Overall, the HIGHLAND HPV110 hydraulic piston pump is a high quality, reliable, and cost-effective option for those in need of a high pressure piston pump for their hydraulic system. Whether you are in the construction, mining, or other heavy-duty industry, this pump is an excellent choice that will provide the power and performance you need to get the job done.
Our Hydraulic Piston Pumps are designed and manufactured to provide reliable and efficient performance in a variety of applications. Our team of technical support professionals is available to assist with any questions or issues that may arise during installation or operation.
We offer a range of services to ensure the continued performance and longevity of our Hydraulic Piston Pumps, including:
Our experienced technicians are equipped with the latest tools and technology to provide fast and effective support. We are committed to delivering high-quality service that exceeds our customers' expectations.
Q: What is the brand name of the hydraulic piston pump?
A: The brand name of the hydraulic piston pump is HIGHLAND.
Q: What is the model number of the hydraulic piston pump?
A: The model number of the hydraulic piston pump is HPV110.
Q: Where is the hydraulic piston pump made?
A: The hydraulic piston pump is made in CHINA DEZHOU.
Q: Does the hydraulic piston pump come with a certification?
A: Yes, the hydraulic piston pump comes with a PATENT CERTIFICATE.
Q: What is the minimum order quantity for the hydraulic piston pump?
A: The minimum order quantity for the hydraulic piston pump is 5 Sets.
Q: What is the price range of the hydraulic piston pump?
A: The price range of the hydraulic piston pump is USD900-1400/Set.
Q: What are the packaging details of the hydraulic piston pump?
A: The hydraulic piston pump is packaged in Plywood Case.
Q: What is the delivery time for the hydraulic piston pump?
A: The delivery time for the hydraulic piston pump is 10 Working Days.
Q: What are the payment terms for the hydraulic piston pump?
A: The payment terms for the hydraulic piston pump are T/T, Western Union.
Q: What is the supply ability of the hydraulic piston pump?
A: The supply ability of the hydraulic piston pump is 200 Sets/Month.
