Product Details:
|
| Usage: | Mobile Crusher | Material: | Cast Iron |
|---|---|---|---|
| Model: | HPV110 Hydraulic Pump | Max Pressure: | 42 MPA |
| Standard Or Nonstandard: | Standard | Max Displacement: | 110ml/r |
| Medium: | Hydraulic Oil | Minimum Order: | 1 Set |
| Highlight: | HPV110 Hydraulic Piston Pumps,Mobile Crusher Hydraulic Piston Pumps,Standard Cast Iron Hydraulic Piston Pumps |
||
This hydraulic piston pump is designed to work with hydraulic oil as its medium, making it suitable for a wide range of applications. Whether you need it for industrial machinery, construction equipment, or agricultural vehicles, the HPV110 hydraulic pump is an excellent choice.
With a minimum order requirement of just one set, this hydraulic pump is accessible to all types of users. Whether you're a small business owner or a large corporation, you can benefit from the reliable performance of the HPV110 hydraulic pump.
The HPV110 hydraulic pump is a model that stands out among other hydraulic piston pumps in the market. Its high pressure capabilities make it ideal for heavy-duty applications that require a lot of power. This pump can deliver consistent and reliable performance, even under tough conditions.
Overall, the HPV110 hydraulic pump is a top-of-the-line product that is perfect for anyone who needs a high-quality hydraulic piston pump. Its cast iron construction and hydraulic transmission working principle make it a durable and reliable choice for any hydraulic system. With a minimum order requirement of just one set, it's easy to get your hands on this exceptional product.
| Max Pressure | 42 MPA |
| Material | Cast Iron |
| Standard Or Nonstandard | Standard |
| Power Source | Hydraulic |
| Max Displacement | 110ml/r |
| Minimum Order | 1 Set |
| Working Principle | Hydraulic Transmission |
| Medium | Hydraulic Oil |
| Usage | Mobile Crusher |
| Warranty | 1 Year |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
High quality hydraulic pump, HPV110 hydraulic pump
The HIGHLAND HPV110 hydraulic piston pump is a versatile product that can be used in different scenarios and occasions. It is widely used in the construction industry for various applications such as excavators, bulldozers, and loaders. This hydraulic piston pump is also used in the agricultural sector for tractors, harvesters, and other farming equipment. The product is also suitable for use in the mining industry, where it is used in drilling rigs, rock crushers, and other mining equipment.
The hydraulic piston pump is ideal for any application that requires a high-pressure pump to move fluid. The pump is designed to deliver consistent and reliable performance, and its hydraulic transmission principle ensures efficiency in operation. The product comes with a 1-year warranty, which assures the buyer of its quality and durability. With a supply ability of 200 sets per month, the HIGHLAND HPV110 hydraulic piston pump is readily available for purchase.
In summary, if you are looking for a high-pressure piston pump for sale, the HIGHLAND HPV110 hydraulic piston pump is a great choice. Its hydraulic transmission principle ensures efficiency and reliability in operation, making it suitable for use in various industrial applications. Furthermore, the product comes with a 1-year warranty, and its packaging details ensure its safety during transportation.
Q1: Could I have a sample order?
A: Yes, we welcome sample order to test and check quality.
Q2: How do you ship the goods and how long does it take to arrive?
A: Ship by air express, it takes 3-5 days to arrive. Airline and sea shipping also optional.
Q3: Do you offer guarantee for the products?
A: Each motor or pump should be tested before shipping, test report can be sent if requested.
Warranty 12 months after shipment for complete assembly.
Q4: What are the payment terms?
A: Full order: 30% as deposit, balance before shipment.
Small order/sample order: Full advance payment.
Q5: Are you manufacturer?
We are a manufacturer with own plant manufacturing hydraulic piston pumps, and we have 20 years experiences in hydraulic industry for oversea and domestic markets.
