Product Details:
|
| Max Displacement: | 110ml/r | Medium: | Hydraulic Oil |
|---|---|---|---|
| Working Principle: | Hydraulic Transmission | Minimum Order: | 1 Set |
| Loading Mode: | Manual Loading | Warrantry: | 1 Year |
| Power Source: | Hydraulic | Standard Or Nonstandard: | Standard |
| Highlight: | HPV110 Hydraulic Piston Pump,Manual Loading Hydraulic Piston Pump,High Pressure Hydraulic Piston Pump |
||
With a max displacement of 110ml/r, this pump is perfect for a wide range of industrial and agricultural applications. Its manual loading mode allows for precise control, while its hydraulic transmission working principle ensures consistent performance and reliability.
And with a 1-year warranty, you can rest easy knowing that your investment in the HPV110 hydraulic pump is protected.
So whether you're looking to power a hydraulic press, drive a hydraulic motor, or simply move fluids through your system, the HPV110 hydraulic pump is the perfect choice. Don't settle for anything less than the best - choose the HPV110 hydraulic pump for all your hydraulic pumping needs!
| Parameter | Value |
|---|---|
| Product Name | HPV110 Hydraulic Piston Pump |
| Material | Cast Iron |
| Minimum Order | 1 Set |
| Medium | Hydraulic Oil |
| Warranty | 1 Year |
| Loading Mode | Manual Loading |
| Usage | Mobile Crusher |
| Max Pressure | 42 MPA |
| Power Source | Hydraulic |
| Working Principle | Hydraulic Transmission |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
This hydraulic pump is suitable for a variety of applications and occasions, including but not limited to:
The HPV110 hydraulic pump has a minimum order quantity of 5 sets and is priced between USD 900-1400 per set. It comes packaged in a sturdy plywood case and has a delivery time of 10 working days. Payment terms include T/T and Western Union, while the supply ability is 200 sets per month.
In conclusion, the HIGHLAND HPV110 hydraulic pump is a versatile and reliable hydraulic pump that can be used in various applications and scenarios. Its high-quality design, hydraulic transmission principle, and manual loading mode make it an ideal choice for heavy-duty operations.
Q1: Could I have a sample order?
A: Yes, we welcome a sample order to test and check quality.
Q2: How do you ship the goods and how long does it take to arrive?
A: Ship by air express, it takes 3-5 days to arrive. Airline and sea shipping also optional.
Q3: Do you offer guarantee for the products?
A: Each motor or pump should be tested before shipping, test report can be sent if requested.
Warranty: 1 year.
Q4: What are the payment terms?
A: Full order: 40% as deposit, balance before shipment.
Small order/sample order: Full advance payment.
Q5: Are you manufacturer?
We are a manufacturer with own plant manufacturing producing hydraulic pumps and motors.
20 years experience in hydraulic industry for oversea and domestic markets. Main business range is hydraulic motor pump system, piston pumps and motors, welcome to visit our factory in Dezhou city Shandong province.
