Product Details:
|
| Power Source: | Hydraulic | Model: | HPV110 Hydraulic Pump |
|---|---|---|---|
| Standard Or Nonstandard: | Standard | Minimum Order: | 1 Set |
| Working Principle: | Hydraulic Transmission | Medium: | Hydraulic Oil |
| Material: | Cast Iron | Loading Mode: | Manual Loading |
| Highlight: | Cast Iron Hydraulic Piston Pump,High Quality Hydraulic Piston Pump,Mobile Crushers Hydraulic Piston Pump |
||
Our hydraulic piston pumps are specifically designed for use with hydraulic oil, making them a perfect fit for a broad range of applications in the industrial, commercial, and agricultural sectors. These pumps are built to last and come with a 1-year warranty, giving you peace of mind and ensuring that you get the most value out of your investment.
Our Hydraulic Piston Pumps are standard in design and can be customized to meet your specific requirements. We offer a minimum order quantity of 1 set, making it easy for you to order the exact number of pumps you need to get the job done.
Our hydraulic piston pumps work on the principle of hydraulic transmission, which means they are designed to deliver high-pressure hydraulic fluid to your system. This makes them ideal for applications that require high-pressure fluid flow, such as in hydraulic presses, machine tools, and other industrial machinery.
When it comes to high-quality hydraulic piston pumps, our products are among the best in the industry. We use only the highest quality materials and manufacturing processes to ensure that our pumps meet and exceed your expectations. So whether you need a high-pressure piston pump for a specific application or are looking for a reliable and efficient hydraulic pump for general use, our Hydraulic Piston Pumps are the perfect solution.
High quality hydraulic pump, piston pump for sale, hydraulic piston pump
| Model | HPV110 Hydraulic Pump |
| Max Pressure | 42 MPA |
| Power Source | Hydraulic |
| Minimum Order | 1 Set |
| Warranty | 1 Year |
| Material | Cast Iron |
| Max Displacement | 110ml/r |
| Standard Or Nonstandard | Standard |
| Loading Mode | Manual Loading |
| Usage | Mobile Crusher |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
One of the most common applications for the HPV110 hydraulic pump is in mobile crushers. These machines require a powerful and reliable hydraulic system to operate, making the HPV110 an ideal choice. Its power source is hydraulic, and it has a max displacement of 110ml/r.
Other potential uses for the HIGHLAND HPV110 hydraulic pump include heavy machinery, construction equipment, and industrial applications. Its versatility and durability make it a popular choice for a wide range of scenarios.
If you're in the market for a high-quality hydraulic pump, the HPV110 is an excellent choice. With a minimum order quantity of just 1 set and a price range of USD900-1400/set, it is an affordable and accessible option for businesses of all sizes. The packaging details include a sturdy plywood case to ensure that the product arrives at your location in excellent condition.
With a supply ability of 200 sets/month and a delivery time of just 10 working days, the HIGHLAND HPV110 hydraulic pump is an excellent choice for businesses that need reliable and efficient hydraulic systems. Payment terms include T/T and Western Union, providing flexibility and convenience for customers.
Q1: Could I have a sample order?
A: Yes, we welcome a sample order to test and check quality.
Q2: How do you ship the goods and how long does it take to arrive?
A: Ship by air express, it takes 3-5 days to arrive. Airline and sea shipping also optional.
Q3: Do you offer guarantee for the products?
A: No one can match our dedication to quality, honesty and value. Experienced hydraulic pump experts, experienced customer service, experienced technicians dedicated to their work, process each and every order. Each order is carefully inspected before it leaves our facility.
Also we offer 1 year gurantee.
Q4: What are the payment terms?
A: Full order: 30% as deposit, balance paid before shipment.
Small order/sample order: Full advance payment.
Q5: Are you manufacturer?
We are a manufacturer with own plant manufacturing producing hydraulic pumps and motors.
20 years experience in hydraulic industry for oversea and domestic markets. Main business range is hydraulic motor pump system, piston pumps and motors, welcome to visit our factory in Dezhou city Shandong province.
Tags: high quality hydraulic pump, piston pump for sale, hydraulic piston pump for mobile crusher
