Product Details:
|
| Model: | HPV110 Hydraulic Pump | Warrantry: | 1 Year |
|---|---|---|---|
| Max Displacement: | 110ml/r | Working Principle: | Hydraulic Transmission |
| Standard Or Nonstandard: | Standard | Material: | Cast Iron |
| Medium: | Hydraulic Oil | Minimum Order: | 1 Set |
| Highlight: | 110ml/r Hydraulic Pump,HPV110 Hydraulic Pump |
||
Our hydraulic piston pump is made with top-of-the-line materials, ensuring durability and longevity. It has a maximum displacement of 110 ml/r, making it suitable for a range of applications.
With its hydraulic transmission working principle, our hydraulic piston pump delivers smooth and consistent performance. It is designed to work with hydraulic oil, making it a versatile and flexible choice for your hydraulic system.
We stand behind the quality of our hydraulic piston pump and offer a 1-year warranty for your peace of mind. Our team of experts is always available to provide support and answer any questions you may have about our products.
Trust in our hydraulic piston pump to deliver the power and performance you need for your machinery. Order now and experience the difference for yourself!
| Model | HPV110 Hydraulic Pump |
| Material | Cast Iron |
| Working Principle | Hydraulic Transmission |
| Max Displacement | 110ml/r |
| Medium | Hydraulic Oil |
| Max Pressure | 42 MPA |
| Usage | Mobile Crusher |
| Warranty | 1 Year |
| Minimum Order | 1 Set |
| Standard Or Nonstandard | Standard |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
High quality hydraulic pump, high pressure piston pump, piston pump for sale.
The HIGHLAND HPV110 hydraulic pump is powered by hydraulic oil and is used as a power source for mobile crushers. Its compact design and high efficiency make it a popular choice for various applications, including construction, mining, and agriculture. This piston pump for sale is known for its ability to handle high-pressure and high-flow applications, making it suitable for heavy-duty machinery.
The HIGHLAND HPV110 hydraulic piston pump is designed to be used in various occasions and scenarios. It is ideal for applications that require high pressure and flow rates, such as mobile crushers, excavators, and loaders. The pump is also suitable for use in hydraulic presses, injection molding machines, and other industrial machinery that requires high-efficiency hydraulic power.
The HIGHLAND HPV110 hydraulic piston pump is a versatile product that can be used in various industries and applications. It is a reliable and durable product that is backed by years of research and development. The minimum order for this piston pump for sale is 1 set, making it accessible to small and large businesses alike.
The Hydraulic Piston Pumps product comes with a comprehensive technical support and services package. Our team of experts is available to assist you with any technical questions or issues you may encounter. We offer installation guide and commissioning services to ensure that your pump is operating at optimal levels. Our team can also provide maintenance and repair services to keep your pump running smoothly. We offer training sessions to ensure that your team is properly trained on the operation and maintenance of the pump. Additionally, we offer spare parts and accessories to ensure that your pump is always ready for use. Contact us for more information on our technical support and services package.
Q: What is the brand name of this hydraulic piston pump?
A: The brand name of this hydraulic piston pump is HIGHLAND.
Q: What is the model number of this hydraulic piston pump?
A: The model number of this hydraulic piston pump is HPV110.
Q: Where is this hydraulic piston pump manufactured?
A: This hydraulic piston pump is manufactured in CHINA DEZHOU.
Q: Does this hydraulic piston pump come with any certification?
A: Yes, this hydraulic piston pump comes with a PATENT CERTIFICATE.
Q: What is the minimum order quantity for this hydraulic piston pump, and how much does it cost?
A: The minimum order quantity for this hydraulic piston pump is 5 sets, and it costs USD900-1400 per set.
Q: What is the packaging, delivery time, payment terms, and supply ability for this hydraulic piston pump?
A: The packaging for this hydraulic piston pump is a Plywood Case. The delivery time is 10 working days. The payment terms are T/T and Western Union. The supply ability is 200 sets per month.
Tags: HPV110 hydraulic pump, hydraulic transmission principle, 110ml/r displacement hydraulic pump
