Product Details:
|
| Max Displacement: | 110ml/r | Power Source: | Hydraulic |
|---|---|---|---|
| Loading Mode: | Manual Loading | Material: | Cast Iron |
| Model: | HPV110 Hydraulic Pump | Medium: | Hydraulic Oil |
| Max Pressure: | 42 MPA | Warrantry: | 1 Year |
| Highlight: | 42 MPA Hydraulic Piston Pumps,110ml/r Hydraulic Piston Pumps,110ml/r Piston Pumps |
||
Made with cast iron material, our hydraulic piston pump is durable and can withstand heavy use. With a maximum displacement of 110ml/r, you can be sure that our pump can handle your crusher's hydraulic system with ease.
You can order our hydraulic piston pump in a minimum quantity of 1 set, making it accessible for any size of business. We are confident in the quality of our product, which is why we offer a 1-year warranty for your peace of mind.
Our HPV110 hydraulic pump is specially designed for mobile crusher use. It provides constant flow and pressure to ensure your crusher operates smoothly and efficiently.
Investing in our hydraulic piston pump means investing in the long-term success of your mobile crusher. With its high-quality construction and reliable performance, you can trust that it will keep your crusher running smoothly for years to come. Don't settle for anything less than the best. Choose our HPV110 hydraulic pump for your mobile crusher needs.
| Technical Parameter | Value |
|---|---|
| Model | HPV110 Hydraulic Pump |
| Loading Mode | Manual Loading |
| Max Pressure | 42 MPA |
| Standard Or Nonstandard | Standard |
| Working Principle | Hydraulic Transmission |
| Warranty | 1 Year |
| Max Displacement | 110ml/r |
| Minimum Order | 1 Set |
| Material | Cast Iron |
| Medium | Hydraulic Oil |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 3 | |
With a maximum pressure of 42 MPA, this piston pump is capable of providing the high pressure needed to power mobile crushers. Its standard loading mode is manual, which makes it easy to use and maintain. It is also a standard size, making it easy to replace worn-out pumps with the HIGHLAND model.
Due to its robust design and reliable performance, the HPV110 Hydraulic Piston Pump is an excellent choice for mobile crusher applications. It is particularly suitable for use in harsh environments where other types of pumps may fail.
Whether you are looking for a piston pump for sale to replace an existing pump or to install in a new mobile crusher, the HPV110 is a great choice. It comes with a patent certificate and has a minimum order quantity of 5 sets. The price range for a single set is between USD900-1400, making it an affordable option for businesses looking to upgrade their equipment.
When you order the HIGHLAND HPV110 Hydraulic Piston Pump, you can expect it to arrive in a plywood case, ensuring that it is protected during shipping. Delivery typically takes 10 working days, and payment can be made via T/T or Western Union. With a supply ability of 200 sets per month, HIGHLAND can meet the needs of businesses of all sizes.
In summary, the HIGHLAND HPV110 Hydraulic Piston Pump is a reliable and robust pump that is ideal for mobile crusher applications. Its high pressure capabilities, standard loading mode, and durable cast iron material make it an excellent choice for businesses looking to upgrade their equipment. Order now and experience the benefits of HIGHLAND's hydraulic piston pump for sale.
Q1: Could I have a sample order?
A: Yes, we welcome a sample order to test and check quality.
Q2: How do you ship the goods and how long does it take to arrive?
A: Ship by air express, it takes 3-5 days to arrive. Airline and sea shipping also optional.
Q3: Do you offer guarantee for the products?
A: No one can match our dedication to quality, honesty and value. Experienced hydraulic pump experts, experienced customer service, experienced technicians dedicated to their work, process each and every order. Each order is carefully inspected before it leaves our facility.
Also we offer 1 year gurantee.
Q4: What are the payment terms?
A: Full order: 30% as deposit, balance paid before shipment.
Small order/sample order: Full advance payment.
Q5: Are you manufacturer?
We are a manufacturer with own plant manufacturing producing hydraulic pumps and motors.
20 years experience in hydraulic industry for oversea and domestic markets. Main business range is hydraulic motor pump system, piston pumps and motors, welcome to visit our factory in Dezhou city Shandong province.
