Product Details:
|
| Medium: | Hydraulic Oil | Minimum Order: | 1 Set |
|---|---|---|---|
| Max Displacement: | 110ml/r | Max Pressure: | 42 MPA |
| Usage: | Mobile Crusher | Material: | Cast Iron |
| Power Source: | Hydraulic | Loading Mode: | Manual Loading |
| Highlight: | 110cc Hydraulic Piston Pump,Manual Loading Hydraulic Piston Pump,Mobile Crusher Hydraulic Piston Pump |
||
Our hydraulic piston pumps are specifically designed to handle hydraulic oil as a medium, with a maximum pressure capacity of 42 MPA. As a standard product, you can trust that our hydraulic piston pumps are built to meet industry standards and perform consistently over time.
Our hydraulic piston pumps are also manual loading, making them easy to use and operate. Whether you are looking for a piston pump for sale for your manufacturing operation, construction site, or any other industrial application, our hydraulic piston pumps are a top choice.
Our hydraulic piston pumps are made from high-quality cast iron, ensuring their durability and longevity. This material is also resistant to wear and tear, corrosion, and other forms of damage that can occur in industrial environments.
With our hydraulic piston pumps, you can trust that you are getting a reliable and efficient product that will help you get the job done right. So why wait? Browse our selection of hydraulic piston pumps today and find the perfect fit for your needs!
| Working Principle | Hydraulic Transmission |
|---|---|
| Model | HPV110 Hydraulic Pump |
| Max Pressure | 42 MPA |
| Max Displacement | 110ml/r |
| Power Source | Hydraulic |
| Warranty | 1 Year |
| Material | Cast Iron |
| Loading Mode | Manual Loading |
| Standard or Nonstandard | Standard |
| Minimum Order | 1 Set |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
With a minimum order quantity of 5 sets and a price range of USD900-1400 per set, this hydraulic piston pump for sale is an affordable and efficient option for a variety of occasions and scenarios.
The HIGHLAND HPV110 Hydraulic Piston Pump is perfect for manual loading, and has a max displacement of 110ml/r. Its hydraulic transmission working principle ensures smooth and reliable operation, making it ideal for a range of applications.
Each pump comes packaged in a sturdy plywood case for protection during transport, and has a delivery time of 10 working days. Payment terms include T/T and Western Union, and the supply ability is 200 sets per month.
Whether you need a hydraulic pump for agricultural, construction, or industrial purposes, the HIGHLAND HPV110 Hydraulic Piston Pump is an excellent choice. Plus, it comes with a 1 year warranty for added peace of mind.
Q1: Could I have a sample order?
A: Yes, we welcome a sample order to test and check quality.
Q2: How do you ship the goods and how long does it take to arrive?
A: Ship by air express, it takes 3-5 days to arrive. Airline and sea shipping also optional.
Q3: Do you offer guarantee for the products?
A: No one can match our dedication to quality, honesty and value. Experienced hydraulic pump experts, experienced customer service, experienced technicians dedicated to their work, process each and every order. Each order is carefully inspected before it leaves our facility.
Also we offer 1 year gurantee.
Q4: What are the payment terms?
A: Full order: 30% as deposit, balance paid before shipment.
Small order/sample order: Full advance payment.
Q5: Are you manufacturer?
We are a manufacturer with own plant manufacturing producing hydraulic pumps and motors.
20 years experience in hydraulic industry for oversea and domestic markets. Main business range is hydraulic motor pump system, piston pumps and motors, welcome to visit our factory in Dezhou city Shandong province.
Tags: 110cc/r hydraulic piston pump, hydraulic pump for mobile crusher, manual loading hydraulic pump
