Product Details:
|
| Warrantry: | 1 Year | Max Pressure: | 42 MPA |
|---|---|---|---|
| Medium: | Hydraulic Oil | Model: | HPV110 Hydraulic Pump |
| Max Displacement: | 110ml/r | Loading Mode: | Manual Loading |
| Power Source: | Hydraulic | Standard Or Nonstandard: | Standard |
| Highlight: | 42MPA Hydraulic Piston Pumps,110ml/r Hydraulic Piston Pumps,High Pressure Hydraulic Piston Pumps |
||
With a minimum order of only 1 set, the HPV110 hydraulic pump is an affordable and reliable option for those in need of a standard loading mode pump. And with a 1 year warranty, you can trust in its longevity and performance.
Whether you're in construction, mining, or any other industry that requires a high quality hydraulic pump, the HPV110 is a standard option that won't let you down.
| Material | Cast Iron |
| Minimum Order | 1 Set |
| Usage | Mobile Crusher |
| Loading Mode | Manual Loading |
| Standard Or Nonstandard | Standard |
| Warrantry | 1 Year |
| Max Displacement | 110ml/r |
| Model | HPV110 Hydraulic Pump |
| Working Principle | Hydraulic Transmission |
| Medium | Hydraulic Oil |
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight | HPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| HMF series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
This high pressure piston pump, HPV110 hydraulic pump, is a standard piston pump for sale that is suitable for manual loading usage in mobile crushers. It comes with a 1-year warranty and has a maximum displacement of 110ml/r. The working principle is hydraulic transmission and the medium used is hydraulic oil.
Quality service
One to one service, can provide design and installation solutions;
Online service for quick response and consultation;
Free door-to-door service to solve difficult after-sales problems;
Fast delivery and good service
A number of invention patents and utility model patent certification, the key components of imported raw materials; Order 7 ~ 20 days fast delivery, 1 year after sales maintenance cycle, for your risk.
Q1: Could I have a sample order?
A: Yes, we welcome a sample order to test and check quality.
Q2: How do you ship the goods and how long does it take to arrive?
A: Ship by air express, it takes 3-5 days to arrive. Airline and sea shipping also optional.
Q3: Do you offer guarantee for the products?
A: No one can match our dedication to quality, honesty and value. Experienced hydraulic pump experts, experienced customer service, experienced technicians dedicated to their work, process each and every order. Each order is carefully inspected before it leaves our facility.
Also we offer 1 year gurantee.
Q4: What are the payment terms?
A: Full order: 30% as deposit, balance paid before shipment.
Small order/sample order: Full advance payment.
Q5: Are you manufacturer?
We are a manufacturer with own plant manufacturing producing hydraulic pumps and motors.
20 years experience in hydraulic industry for oversea and domestic markets. Main business range is hydraulic motor pump system, piston pumps and motors, welcome to visit our factory in Dezhou city Shandong province.
