Product Details:
|
| Max Pressure: | 42 MPA | Max Displacement: | 110ml/r |
|---|---|---|---|
| Medium: | Hydraulic Oil | Loading Mode: | Manual Loading |
| Power Source: | Hydraulic | Usage: | Combine Harvester Etc Agricultural Machinery |
| Material: | Cast Iron | Model: | HPV110-MA-R-23 Hydraulic Pump |
| Highlight: | High Pressure Hydraulic Piston Pumps,Combine Harvester Hydraulic Piston Pumps,HPV110-MA-R-23 Hydraulic Piston Pumps |
||
With a maximum pressure capacity of 42 MPA, these hydraulic piston pumps are capable of handling even the most demanding jobs with ease. Whether you're looking to power a hydraulic system on a construction site or need a reliable pump for your industrial equipment, our hydraulic piston pumps are the perfect choice.
Featuring manual loading, these pumps are easy to operate and require minimal maintenance, making them an ideal choice for businesses of all sizes. And with their ability to handle hydraulic oil as a medium, you can be sure that these pumps will provide reliable and efficient performance for years to come.
At our company, we're proud to offer these top-quality hydraulic piston pumps for sale at competitive prices. And with a minimum order of just 1 set, we make it easy for you to get the pumps you need without breaking the bank.
So why wait? Whether you're looking for a reliable pump for your construction equipment or need a pump for your industrial machinery, our hydraulic piston pumps are the perfect choice. Contact us today to learn more about our products and place your order!
This hydraulic piston pump is a high pressure piston pump for sale that can handle hydraulic oil as its medium. It has a max displacement of 110ml/r and is made of cast iron. The model number for this pump is HPV110-MA-R-23.
| Working Principle | Hydraulic Transmission |
| Loading Mode | Manual Loading |
| Power Source | Hydraulic |
| Max Pressure | 42 MPA |
| Standard Or Nonstandard | Standard |
| Usage | Combine Harvester Etc Agricultural Machinery |
| Minimum Order | 1 Set |
| Max Displacement | 110ml/r |
| Model | HPV110-MA-R-23 Hydraulic Pump |
| Material | Cast Iron |
| HPV Series Technical parameter | ||||||||
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight |
HPV series hydraulic pump hydraulic oil emptying |
kg | 45 | 46 | 63 | 64 | 82 | 88 |
|
HMF series hydraulic motor hydraulic oil emptying |
kg | 30 | 30 | 36 | 36 | 36 | 38 | |
Construction: The HPV110-MA-R-23 hydraulic piston pump is commonly used in construction machinery, such as excavators, loaders, and bulldozers. It can handle heavy loads and provide smooth operation, making it an ideal choice for construction applications.
Agriculture: The hydraulic pump is also used in agricultural machinery, including tractors, harvesters, and sprayers. These machines require a reliable source of power to operate efficiently, and the HPV110-MA-R-23 can provide the necessary power and flow rates.
Manufacturing: In manufacturing facilities, the hydraulic piston pump is used in various applications, including pressing, cutting, and forming. The high-pressure output of the pump makes it an ideal choice for these applications, as it can generate the force required to operate these machines.
Mining: The HPV110-MA-R-23 hydraulic piston pump is also used in the mining industry. It is commonly used in mining equipment such as drilling machines, rock breakers, and excavators. The pump's ability to generate high pressure and flow rates makes it an excellent choice for mining applications.
The HIGHLAND HPV110-MA-R-23 hydraulic piston pump is a standard product with manual loading and a maximum displacement of 110ml/r. The product is certified with a patent certificate and has a minimum order quantity of 5 sets. The price for this high-quality hydraulic pump ranges from USD900-1400 per set, and it comes packaged in a plywood case. The delivery time for the product is 10 working days, and the payment terms accepted are T/T and Western Union. The product is manufactured in CHINA DEZHOU and has a supply ability of 200 sets per month.
Quality service
One to one service, can provide design and installation solutions;
Online service for quick response and consultation;
Free door-to-door service to solve difficult after-sales problems;
Axial piston hydraulic pump has the advantages of simple structure, small size, light weight, low noise, and long service life.
Fast delivery and good service
A number of invention patents and utility model patent certification, the key components of imported raw materials; Order 7 ~ 20 days fast delivery, 1 year after sales maintenance cycle, for your risk.
Q: What is the brand name of the hydraulic piston pump?
A: The brand name of the hydraulic piston pump is HIGHLAND.
Q: What is the model number of the hydraulic piston pump?
A: The model number of the hydraulic piston pump is HPV110-MA-R-23.
Q: Where is the hydraulic piston pump manufactured?
A: The hydraulic piston pump is manufactured in CHINA DEZHOU.
Q: Does the hydraulic piston pump come with any certification?
A: Yes, the hydraulic piston pump comes with a PATENT CERTIFICATE.
Q: What is the minimum order quantity for the hydraulic piston pump?
A: The minimum order quantity for the hydraulic piston pump is 5 sets.
Q: What is the price of the hydraulic piston pump?
A: The price of the hydraulic piston pump ranges from USD900 to USD1400 per set.
Q: What is the packaging detail for the hydraulic piston pump?
A: The packaging detail for the hydraulic piston pump is Plywood Case.
Q: What is the delivery time for the hydraulic piston pump?
A: The delivery time for the hydraulic piston pump is 10 working days.
Q: What are the payment terms for the hydraulic piston pump?
A: The payment terms for the hydraulic piston pump are T/T and Western Union.
Q: What is the supply ability for the hydraulic piston pump?
A: The supply ability for the hydraulic piston pump is 200 sets per month.
Tags: High pressure hydraulic piston pump, HPV110-MA-R-23 hydraulic piston pumps, combine harvester hydraulic piston pumps
