Product Details:
|
| Material: | Cast Iron | Warrantry: | 1 Year |
|---|---|---|---|
| Max Pressure: | 42 MPA | Power Source: | Hydraulic |
| Working Principle: | Hydraulic Transmission | Loading Mode: | Manual Loading |
| Minimum Order: | 1 Set | Model: | HPV110-MA-R-23 Hydraulic Pump |
| Highlight: | Cast Iron Hydraulic Piston Pumps,Manual Loading Hydraulic Piston Pumps,Axial Piston Pumps |
||
With a minimum order of just one set, you can easily acquire the HPV110-MA-R-23 Hydraulic Pump for all of your agricultural needs. Its piston pump design ensures powerful and reliable performance, making it the perfect choice for use in combine harvesters and other agricultural machinery.
Don't settle for subpar hydraulic pumps that may fail when you need them most. Choose the HPV110-MA-R-23 Hydraulic Pump for its superior quality and unbeatable performance. Order yours today and experience the difference for yourself!
Looking for a reliable hydraulic piston pump? Our cast iron hydraulic piston pumps are built to last and come with a 1 year warranty. With hydraulic transmission and powered by hydraulic fluid, these pumps are perfect for a variety of industrial applications. Get your piston pump for sale today!
| Usage | Combine Harvester Etc Agricultural Machinery |
| Model | HPV110-MA-R-23 Hydraulic Pump |
| Loading Mode | Manual Loading |
| Power Source | Hydraulic |
| Standard Or Nonstandard | Standard |
| Working Principle | Hydraulic Transmission |
| Minimum Order | 1 Set |
| Material | Cast Iron |
| Warrantry | 1 Year |
| Max Displacement | 110ml/r |
| HPV Series Technical parameter | ||||||||
| HPV hydraulic pump and HMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| Weight |
HPV series hydraulic pump hydraulic oil emptying |
kg | 45 | 46 | 63 | 64 | 82 | 88 |
|
HMF series hydraulic motor hydraulic oil emptying |
kg | 30 | 30 | 36 | 36 | 36 | 38 | |
Whether you need to move hydraulic oil in manufacturing equipment, agricultural machinery, or construction vehicles, the HPV110 hydraulic pump is a reliable and efficient choice. Its patented design and certification ensure that you're getting a high-quality product that meets your needs.
When you order the HIGHLAND HPV110-MA-R-23, you can expect a minimum order quantity of 5 sets, with a price range of USD900-1400 per set. The product comes packaged in a sturdy plywood case for safe transport, and you can expect delivery within 10 working days. Payment terms include T/T and Western Union, and the supply ability is up to 200 sets per month.
So, whether you're looking for a piston pump for sale to power your industrial machinery or construction equipment, the HIGHLAND HPV110-MA-R-23 is an excellent choice. Made with quality materials and designed for optimal performance, this hydraulic pump is sure to meet your needs and exceed your expectations.
Our Hydraulic Piston Pumps are designed to provide high performance and efficiency for your hydraulic system needs. We offer a range of technical support and services to ensure that your pumps continue to operate at their best:
Our team of experts is dedicated to providing exceptional support and services to help you get the most out of your Hydraulic Piston Pumps.
Q: What is the brand name of the hydraulic piston pump?
A: The brand name of the hydraulic piston pump is HIGHLAND.
Q: What is the model number of the hydraulic piston pump?
A: The model number of the hydraulic piston pump is HPV110-MA-R-23.
Q: Where is the hydraulic piston pump manufactured?
A: The hydraulic piston pump is manufactured in CHINA DEZHOU.
Q: Does the hydraulic piston pump come with any certification?
A: Yes, the hydraulic piston pump comes with a PATENT CERTIFICATE.
Q: What is the minimum order quantity for the hydraulic piston pump?
A: The minimum order quantity for the hydraulic piston pump is 5 sets.
Q: What is the price range for the hydraulic piston pump?
A: The price range for the hydraulic piston pump is USD900-1400 per set.
Q: How is the hydraulic piston pump packaged for delivery?
A: The hydraulic piston pump is packaged in Plywood Case.
Q: What is the delivery time for the hydraulic piston pump?
A: The delivery time for the hydraulic piston pump is 10 working days.
Q: What are the payment terms for purchasing the hydraulic piston pump?
A: The payment terms for purchasing the hydraulic piston pump are T/T and Western Union.
Q: What is the supply ability of the hydraulic piston pump?
A: The supply ability of the hydraulic piston pump is 200 sets per month.
