Product Details:
|
| Max.displacemen: | 70ml/r | Max.pressure: | 42mpa |
|---|---|---|---|
| Model: | LPV70+LMF70 | Quality: | Excellent |
| Material: | Cast Iron | Application: | Rice Harvester |
| Warranty: | 1 Year | Function: | Hydraulic System Components |
| Package: | Pywood Case | Product Name: | LPV70 Mobile Crusher Hydraulic Motor Pump System System Solutions |
| Highlight: | Mobile Crusher Motor Pump System,70ml/r hydraulic motor system,LPV70 Hydraulic Motor Pump System |
||
LPV70 mobile crusher Hydraulic Motor Pump System System Solutions
· cast iron housing
· hydraulic components
· Power components of hydraulic systems
· higher efficiency
· Simple layout
· System Solutions
· work fast
· Fully replace imported products
· Patent certificate certification
· 1 year warranty
· Application rice harvester
· Category Variable displacement axial piston pump
LPV70 mobile crusher Hydraulic Motor Pump System System Solutions information:
A hydraulic pump motor system is an essential component of many agricultural machinery, such as tractors, harvesters, and other heavy equipment. It uses a hydraulic pump to convert mechanical power into hydraulic energy, which then powers the various hydraulic systems of the machinery.
In an agricultural setting, these hydraulic systems are often used for tasks such as lifting and lowering heavy loads, steering, and controlling implements. The hydraulic system allows for precise and efficient control over these functions, making it an important tool for farmers and other agriculture professionals.
The hydraulic pump motor system can be powered by various sources, including the engine of the machinery or a separate auxiliary power unit. It typically consists of a hydraulic pump, hydraulic fluid reservoir, a series of hoses and valves, and a hydraulic motor that converts the hydraulic energy back into mechanical energy.
Specifications:
LPV70 mobile crusher Hydraulic Motor Pump System technical parameter
| LPV hydraulic pump and LMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| weight | LPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| LPV series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
LPV70 mobile crusher Hydraulic Motor Pump System notices:
Use appropriate fluids: Make sure to use the appropriate hydraulic fluid for your system. Not all fluids are compatible with all systems, so check the manufacturer's recommendations.
LPV70 mobile crusher Hydraulic Motor Pump System use:
Mixer truck: concrete mixer truck, cement mixer truck;
Coal mining machinery: scraper;
Industry: pharmaceutical machinery;
Transport vehicles: road rollers, concrete pump trucks, stabilized soil mixers
LPV70 mobile crusher Hydraulic Motor Pump System faq
Q1. Can I have a sample order for rice harvester hydraulic motor pump system?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the rice harvester hydraulic motor pump system lead time?
10 to 15 days for samples, mass production according to MOQ
Q3. Do you have any MOQ limit for rice harvester hydraulic motor pump system?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the rice harvester hydraulic motor pump system and how long does it take to arrive?
Ship by sea, it generally takes 15-20 days to arrive, and air is also optional.
Q5. How to proceed an order for rice harvester hydraulic motor pump system
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6: Do you offer guarantee for therice harvester hydraulic motor pump system?
A: Yes, we offer 1 years warranty to our products.
Q7: How to deal with the faulty rice harvester hydraulic motor pump system?
Firstly, our products are produced in strict quality control system.Secondly, we will inspect the defective pump and motor, and then respond according to the actual situation.
