Product Details:
|
| Max.displacemen: | 50ml/r | Max.pressure: | 42mpa |
|---|---|---|---|
| Model: | LPV50+LMF50 | Quality: | Excellent |
| Material: | Cast Iron | Application: | Rice Harvester |
| Warranty: | 1 Year | Function: | Hydraulic System Components |
| Package: | Pywood Case | Product Name: | LPV50 Agricultural Machinery Hydraulic Motor Pump System Easy To Disassemble |
| Highlight: | 50ml/r hydraulic motor and pump system,LPV50 hydraulic motor system,agricultural machinery hydraulic motor system |
||
LPV50 agricultural machinery Hydraulic Motor Pump System Easy to disassemble
· cast iron housing
· hydraulic components
· Power components of hydraulic systems
· higher efficiency
· Simple layout
· System Solutions
· work fast
· Fully replace imported products
· Patent certificate certification
· 1 year warranty
· Application rice harvester
· Category Variable displacement axial piston pump
LPV50 agricultural machinery Hydraulic Motor Pump System Easy to disassemble information:
Hydraulic pump motor systems have become an essential component in modern agricultural machinery. This system allows farmers and workers to perform a variety of tasks quickly and efficiently, such as lifting heavy loads, adjusting the height of implements, and powering other hydraulic equipment.
The hydraulic pump motor system works by converting mechanical power into hydraulic energy, which is then used to operate cylinders or motors. This system typically consists of a hydraulic pump, motor, reservoir, control valves, and hoses. The hydraulic pump draws oil from the reservoir and sends it through the hoses to the hydraulic motors or cylinders, which then convert the energy into useful work.
In agricultural machinery, this technology is used for a wide range of applications, including plowing fields, lifting heavy loads, and operating seed drills. It offers increased efficiency and productivity, allowing farmers to complete their work faster and with less effort. Furthermore, hydraulic pump motor systems are highly reliable and durable, requiring minimal maintenance and repair over time.
Specifications:
LPV50 agricultural machinery Hydraulic Motor Pump System Easy to disassemble technical parameter
| LPV hydraulic pump and LMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| weight | LPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| LPV series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
LPV50 agricultural machinery Hydraulic Motor Pump System Easy to disassemble notices:
Keep the system clean: Dirt and debris can cause damage to the hydraulic pump motor system. Keep the area around the system clean to prevent debris from entering the system.
LPV50 agricultural machinery Hydraulic Motor Pump System Easy to disassemble use:
Mixer truck: concrete mixer truck, cement mixer truck;
Coal mining machinery: scraper;
Industry: pharmaceutical machinery;
Transport vehicles: road rollers, concrete pump trucks, stabilized soil mixers
LPV50 agricultural machinery Hydraulic Motor Pump System Easy to disassemble faq
Q1. Can I have a sample order for rice harvester hydraulic motor pump system?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the rice harvester hydraulic motor pump system lead time?
10 to 15 days for samples, mass production according to MOQ
Q3. Do you have any MOQ limit for rice harvester hydraulic motor pump system?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the rice harvester hydraulic motor pump system and how long does it take to arrive?
Ship by sea, it generally takes 15-20 days to arrive, and air is also optional.
Q5. How to proceed an order for rice harvester hydraulic motor pump system
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6: Do you offer guarantee for therice harvester hydraulic motor pump system?
A: Yes, we offer 1 years warranty to our products.
Q7: How to deal with the faulty rice harvester hydraulic motor pump system?
Firstly, our products are produced in strict quality control system.Secondly, we will inspect the defective pump and motor, and then respond according to the actual situation.
