Product Details:
|
| Max.displacemen: | 110/r | Max.pressure: | 42mpa |
|---|---|---|---|
| Model: | LPV10+LMF110 | Quality: | Excellent |
| Material: | Cast Iron | Application: | Rice Harvester |
| Warranty: | 1 Year | Function: | Hydraulic System Components |
| Package: | Pywood Case | Product Name: | Manual Control Hydraulic Pump Motor System Customized LPV110 |
| Highlight: | 110/r displacement Motor Pump System,LPV110 Motor Pump System,Manual Control Hydraulic Motor Pump System |
||
Manual Control Hydraulic Pump Motor System Customized LPV110
· cast iron housing
· hydraulic components
· Power components of hydraulic systems
· higher efficiency
· Simple layout
· System Solutions
· work fast
· Fully replace imported products
· Patent certificate certification
· 1 year warranty
· Application rice harvester
· Category Variable displacement axial piston pump
Hydraulic Motor Pump System System Solutions information:
Experience a new level of control with our customized HPV110 Manual Control Hydraulic Pump Motor System. Designed to empower you with more direct, hands-on management of your operations, this robust system greatly enhances the performance and durability of your equipment. The HPV110 system combines innovation and simplicity, providing a manual interface that is both intuitive and effective.
Whether you're navigating complex operations or seeking consistent output, the manually controlled HPV110 system offers precision control, enhancing the operational efficiency of your hydraulic equipment. The system's design ensures its reliability under a range of work conditions, providing a sturdy and durable solution that enhances both productivity and lifespan of your equipment.
Embrace the power of manual control and optimize your operations with the tailored, user-friendly HPV110 Hydraulic Pump Motor System.
Specifications:
Hydraulic Motor Pump System technical parameter
| LPV hydraulic pump and LMF hydraulic motor series | 30 | 50 | 70 | 90 | 110 | 130 | ||
| Displacement | Max displacement | ml/r | 30 | 50 | 70 | 90 | 110 | 130 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 | 2900 | 2900 |
| Rated speed | r/min | 2500 | ||||||
| Min continuous working speed | r/min | 500 | ||||||
| Pressure | Rated working pressure | Mpa | 35 | |||||
| Max working pressure (transient) | Mpa | 42 | ||||||
| Continuous working pressure | Mpa | 30 | ||||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 | 535.3 | 632.4 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | 749 | 885 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 | 149 | 176 |
| Max power | KW | 62 | 95 | 114 | 150 | 173 | 205 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||||
| Max working temperature of oil tank | ℃ | 70 | ||||||
| weight | LPV series hydraulic pump hydraulic oil drain | kg | 45 | 46 | 63 | 64 | 82 | 88 |
| LPV series hydraulic motor hydraulic oil drain | kg | 30 | 30 | 36 | 36 | 36 | 38 | |
Hydraulic Motor Pump System notices:
Regular Inspection: Before each use, the operator should perform a thorough inspection of the hydraulic pump motor system to check for leaks, damage, or any other potential issues.
Correct Usage: Always ensure that the manual control is operated correctly. Incorrect operation can cause the system to malfunction, potentially leading to equipment damage or personal injury.
Hydraulic Oil Maintenance: Regularly check and maintain the hydraulic oil's quality and level. Replace the oil immediately if it becomes contaminated or shows signs of degradation.
Prevent Overheating: The hydraulic system can overheat if used for extended periods. Regularly monitor the system's temperature and take cooling measures if necessary to maintain performance and prevent damage.
Storage: Store the hydraulic pump in a dry, clean, and dust-free environment when not in use to prevent rust or contamination.
Professional Maintenance: If a decrease in system performance or a malfunction is detected, stop using it immediately and call a professional technician for inspection and repair.
Hydraulic Motor Pump System use:
Mixer truck: concrete mixer truck, cement mixer truck;
Coal mining machinery: scraper;
Industry: pharmaceutical machinery;
Transport vehicles: road rollers, concrete pump trucks, stabilized soil mixers
Hydraulic Motor Pump System faq
Q1. Can I have a sample order for hydraulic motor pump system?
A: Yes, we welcome sample order to test and check quality.
Q2. What about the hydraulic motor pump system lead time?
10 to 15 days for samples, mass production according to MOQ
Q3. Do you have any MOQ limit for hydraulic motor pump system?
A: Low MOQ, 1pc for sample checking is available.
Q4. How do you ship the hydraulic motor pump system and how long does it take to arrive?
Ship by sea, it generally takes 15-20 days to arrive, and air is also optional.
Q5. How to proceed an order for hydraulic motor pump system
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6: Do you offer guarantee for the hydraulic motor pump system?
A: Yes, we offer 1 years warranty to our products.
Q7: How to deal with the faulty hydraulic motor pump system?
Firstly, our products are produced in strict quality control system.Secondly, we will inspect the defective pump and motor, and then respond according to the actual situation.
