Product Details:
|
| Product Model: | PV23 Hydraulic Pumps | Displacement: | 89.0ml/r |
|---|---|---|---|
| Type: | Hydraulic Components | Structure: | Axial Piston Pump |
| Material: | Cast Iron | Principle: | Hydraulic Transmission |
| Medium: | Hydraulic Oil | Warranty: | 1 Year |
| Function: | Hydraulic System Components | Package: | Plywood Case |
| Highlight: | PV23 Cement Mixer Hydraulic Pump,89.0ml/R cement mixer hydraulic pump,3200rpm cement truck hydraulic pumps |
||
Ready cement mixer PV23 hydraulic pumps withstand overload test
Ready cement mixer hydraulic pump product introduction:
The hydraulic pump of the mixer truck consist of closed hydraulic transmission system. The engine power in mixer is transferred to the hydraulic pump by the transmission shaft, and the hydraulic pump transmits the hydraulic energy to the hydraulic motor, which drives the reducer to drive the mixing tank, so as to realize the function of loading, mixing and unloading.
PV23 hydraulic pumps main features:
PV23 hydraulic pumps technical specifications:
| 20 series PV hydraulic pump and MF hydraulic motor | 20 | 21 | 22 | 23 | ||
| Displacement | Max displacement | ml/r | 33.3 | 51.6 | 69.8 | 89.0 |
| Speed | Max continuous working speed (Full load condition) |
r/min | 3500 | 3500 | 3200 | 3200 |
| Rated speed | r/min | 2500 | ||||
| Min continuous working speed | r/min | 500 | ||||
| Pressure | Rated working pressure | Mpa | 35 | |||
| Max working pressure (transient) | Mpa | 42 | ||||
| Continuous working pressure | Mpa | 30 | ||||
| Allowable shell pressure (Absolute) | Mpa | Constant0.25, Peak value0.5 | ||||
| Torque | Continuous output torque (Under continuous working pressure) |
Nm | 162.3 | 252.3 | 342.6 | 432.9 |
| Max output torque | Nm | 227 | 353 | 480 | 606 | |
| Power | Continuous output power | KW | 45 | 79 | 107 | 139 |
| Max power | KW | 62 | 95 | 114 | 150 | |
| Temperature | Allowable shell temperature | ℃ | 80 | |||
| Max working temperature of oil tank | ℃ | 70 | ||||
| Weight |
PV series hydraulic pump hydraulic oil emptying |
kg | 45 | 53 | 63 | 78 |
|
PV series hydraulic motor hydraulic oil emptying |
kg | 30 | 34 | 40 | 47 | |
Company service of PV23 hydraulic pumps:
1.One-stop hydraulic pump service for all the top mixer truck brands .
2.We have more than 20 years of experience in the hydraulic pump industry and our superior manufacturing process meet all kinds of hydraulic pumps according to OEM standards.
3. We have implemented the highest quality control system possible to ensure the stability and quality of our mixer piston pumps.
4.Our sales team is experienced and trained to understand your request and help you find the best solution for your needs.
FAQ of PV23 mixer hydraulic pump:
Q1: Could we place sample order of mixer hydraulic pump?
A: Yes, welcome sample order to test and check quality firstly.
Q2: Do you offer guarantee for mixer hydraulic pump?
A: Each pump will be tested before shipping. Warranty 12 months after shipment for complete assembly.
Q3: What are the payment terms?
A: Full order: 30% T/T prepayment, balance paid before shipment. Small order/sample order: Full advance payment.
Q4: Are you manufacturer?
We are a manufacturer with own plant manufacturing hydraulic pump. We have 20 years experience in hydraulic industry for overseas and domestic markets.
Tags: mixer hydraulic pumps, ready cement hydraulic pumps, PV23 mixer hydraulic pumps
