Product Details:
|
| Characteristic: | Accurate | Max Pressure: | 420 Bar |
|---|---|---|---|
| Usage: | Cement Mixer | Advantage: | Data Display |
| Brand: | HIGHLAND | Function: | Test Hydraulic Flow Rate,Pressure,Temperature |
| Oil Temperature Range: | -20℃ -150℃ | ||
| Highlight: | Cement Mixer Accurate Hydraulic Tester,Industrial Cement Mixer Hydraulic Tester |
||
The MYHT-1-4 Hydraulic Tester from HIGHLAND is an efficient and accurate hydraulic flow meter designed to test hydraulic flow rate, pressure, and temperature. It has a maximum pressure of 420 bar and is ideal for hydraulic pump flow testing and hydraulic efficiency testing. HIGHLAND is a renowned manufacturer of quality hydraulic testers, and the MYHT-1-4 Hydraulic Tester is no exception, offering superior accuracy and reliability. With its precise measurements and easy installation, the MYHT-1-4 Hydraulic Tester is the perfect choice for your hydraulic testing needs.
| MYHT Hydraulic Tester Technial Date | ||||||
| Model | Flow(L/min) | Flow Precision | Pressure(bar) | Oil Temperature(°C) | Dimensions(mm) | Weight(Kg) |
| MYHT-1-2 | 200 | ±1% | 420 | 150 | 295*265*210 | 6.1 |
| MYHT-1-4 | 400 | ±1% | 420 | 150 | 295*265*210 | 8.8 |
| MYHT-1-5 | 500 | ±1% | 420 | 150 | 295*265*210 | 10.5 |
| MYHT-1-7 | 800 | ±1% | 420 | 150 | 310*285*261 | 14 |
HIGHLAND MYHT-1-4 Hydraulic Flow Meters are designed to accurately measure and test hydraulic flow rate, pressure, and temperature. With its CE certification, it is highly reliable and safe to use. It can be used with a cement mixer to ensure accurate data display. This hydraulic tester comes with a maximum pressure of 420 bar and is certified for use with a variety of hydraulic pumps. With its wooden case packaging and 1 set minimum order quantity, it is easy to ship and use. It is available for USD1750/set with a delivery time of 15-30 working days and payment terms of T/T, Western Union. Moreover, HIGHLAND MYHT-1-4 Hydraulic Flow Meters are capable of producing up to 100 sets per month.
Brand Name: HIGHLAND
Model Number: MYHT-1-4
Place of Origin: China Dezhou
Certification: CE
Minimum Order Quantity: 1set
Price: USD1750/set
Packaging Details: Wooden case
Delivery Time: 15-30 working days
Payment Terms: T/T, Western Union
Supply Ability: 100 sets per month
Usage: Cement Mixer
Advantage: Data Display
Product Name: MYHT-1-4 Hydraulic Tester
Flow Rate: 400L/min
Max Pressure: 420 Bar
Hydraulic Flow Meters are packaged in wooden cases depending on the size and type of the product. The equipment is labeled with the item's model and serial number, and is secured with packing tape. Additional packing materials may be used to provide extra protection. The boxes are then shipped via ground, air, or sea transportation.
