HIGHLAND Clear Pipeline Connection Rotary Drilling Rig YST380 Hydraulic Test Stands Customization

HIGHLAND Clear Pipeline Connection Rotary Drilling Rig YST380 Hydraulic Test Stands Customization
HIGHLAND Clear Pipeline Connection Rotary Drilling Rig YST380 Hydraulic Test Stands Customization
HIGHLAND Clear Pipeline Connection Rotary Drilling Rig YST380 Hydraulic Test Stands Customization HIGHLAND Clear Pipeline Connection Rotary Drilling Rig YST380 Hydraulic Test Stands Customization HIGHLAND Clear Pipeline Connection Rotary Drilling Rig YST380 Hydraulic Test Stands Customization HIGHLAND Clear Pipeline Connection Rotary Drilling Rig YST380 Hydraulic Test Stands Customization

Large Image :  HIGHLAND Clear Pipeline Connection Rotary Drilling Rig YST380 Hydraulic Test Stands Customization

Product Details:
Place of Origin: China Dezhou
Brand Name: HIGHLAND
Certification: CE
Model Number: YST380 Series
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD25000-45000/set
Packaging Details: Plastic film packaging
Delivery Time: 30-60 working days
Payment Terms: T/T, Western Union
Supply Ability: 5 sets per month

HIGHLAND Clear Pipeline Connection Rotary Drilling Rig YST380 Hydraulic Test Stands Customization

Description
Power: 90 Kw Usage: Rotary Drilling Rig
Advantage: Clear Pipeline Connection Pressure: 35 Mpa
Flow Rate: 380 L/min Show Location: Locale
Brand: HIGHLAND Characteristic: Compact Structure
Highlight:

YST380 Hydraulic Test Bench

,

Clear Pipeline Connection Hydraulic Test Stands

,

Rotary Drilling Rig Hydraulic Test Stands

Product Description:



Hydraulic Test Stands from a professional Hydraulic Test Stands factory is the most reliable and efficient hydraulic pressure testing device, designed for rotary drilling rigs. It features a unique and compact structure, with clear pipeline connection and a flow rate up to 380 L/min, making it ideal for local applications.



HIGHLAND Clear Pipeline Connection Rotary Drilling Rig YST380 Hydraulic Test Stands Customization 0



Features:



  • Product Name: Hydraulic Test Stands
  • Brand: HIGHLAND
  • Show location: Locale
  • Power: 90 Kw
  • Characteristic: Compact Structure
  • Advantage: Clear Pipeline Connection
  • Keywords: Hydraulic Performance Test Machine, Hydraulic Test Stands Factory, Hydraulic Test Stands Factory



Technical Parameters:



Pressure(mpa) 35mpa/42mpa
Flow rate(L/min) 380L/min / 450L/min / 500L/min
Power(KW) 75kw / 90kw / 110kw / 160kw / 200kw / 250kw / 315kw
Power Drive Mode Electromotor / Diesel engine drive / Hydraulic motor / Power recovery
Speed Range 1000r/min / 0-1500r/min / 0-2500r/min
Load location Liquid control loading / Proportional loading
Show location Locale/ Computer (long-distance)
Working Medium Hydraulic oil
Composition Pressure, flow, speed, displacement and volume, open and closed pumps, left and right rotation items, motors, oil cylinders, torque, power, computer generated test reports, graphs, computer collected data, printouts
Applicable area Apply to performance test of the hydraulic components that supported by a host in engineering machinery, metallurgical, petroleum, machinery, aerospace, shipbuilding and other fields.



HIGHLAND Clear Pipeline Connection Rotary Drilling Rig YST380 Hydraulic Test Stands Customization 1



Applications:



Hydraulic Test Stands from HIGHLAND are designed to provide a comprehensive solution for all Hydraulic System Testing needs. Our YST380 Series of Hydraulic Test Stands is an excellent choice, offering a compact structure, clear pipeline connection, and a maximum pressure of 35 Mpa. With a power of 90 Kw, these testing machines are suitable for use in rotary drilling rigs and other heavy-duty industrial tasks. It also comes with CE certification, ensuring that it meets all safety requirements.

Our Hydraulic Test Stands provide a reliable and efficient way to test the performance of hydraulic systems. With an easy-to-use interface, they can help identify and diagnose problems quickly and accurately. The test stands are also very cost-effective, with prices ranging from USD25000-45000/set, and a minimum order quantity of 1set. We also offer a flexible payment plan, including T/T and Western Union, and a quick delivery time of 30-60 working days.

At HIGHLAND, we are committed to providing the best Hydraulic Test Stands for all your testing needs. Our machines are designed to be durable and reliable, with a supply ability of 5 sets per month. All our products come with plastic film packaging for added protection. With our high-quality Hydraulic Test Stands, you can be confident in having a reliable and accurate testing system for your hydraulic systems.



Customization:



Brand Name: HIGHLAND
Model Number: YST380 Series
Place of Origin: China Dezhou
Certification: CE
Minimum Order Quantity: 1set
Price: USD25000-45000/set
Packaging Details: Plastic film packaging
Delivery Time: 30-60 working days
Payment Terms: T/T, Western Union
Supply Ability: 5 sets per month
Product Name: Hydraulic Test Stands
Advantage: Clear Pipeline Connection
Flow rate: 380 L/min
Show location: Locale
Usage: Rotary Drilling Rig

Features:
  • Hydraulic Pressure Testing Device
  • Hydraulic System Testing
  • Hydraulic Performance Test Machine



HIGHLAND Clear Pipeline Connection Rotary Drilling Rig YST380 Hydraulic Test Stands Customization 2



Packing and Shipping:



Hydraulic Test Stands are packaged in plastic film packaging for safe shipping.

We use reputable shipping companies to ensure the safe delivery of our Hydraulic Test Stands. Delivery times may vary depending on the destination.



FAQ:



Q1: What is the brand of the Hydraulic Test Stands?

A1: The brand of the Hydraulic Test Stands is HIGHLAND.

Q2: What is the Model Number of the Hydraulic Test Stands?

A2: The Model Number of the Hydraulic Test Stands is YST380 Series.

Q3: Where are the Hydraulic Test Stands made?

A3: The Hydraulic Test Stands are made in China Dezhou.

Q4: What is the Certification of the Hydraulic Test Stands?

A4: The Certification of the Hydraulic Test Stands is CE.

Q5: What is the minimum order quantity for the Hydraulic Test Stands?

A5: The minimum order quantity for the Hydraulic Test Stands is 1 set.
