Product Details:
|
| Usage: | Excavators | Flow Rate: | 380 L/min |
|---|---|---|---|
| Product Name: | Hydraulic Test Stands | Power: | 110 Kw |
| Pressure: | 42 Mpa | Advantage: | Compact Structure |
| Show Location: | Locale | Characteristic: | Patented Product |
Hydraulic Test Stands, a customized hydraulic pressure testing device factory, is designed to provide customers with reliable testing data and results. With a maximum pressure of 42 Mpa and a power of 110 Kw, it has a flow rate of up to 380 L/min. It is widely used in the field of hydraulic pressure detection and testing, and is a reliable and accurate testing device. Moreover, it has a high degree of automation and localization support. It can be used in any locale for quick and efficient testing. Hydraulic Test Stands offers customers a top-quality testing experience, with its high precision, fast response, and reliable performance.
| Pressure(mpa) | 35mpa/42mpa |
| Flow rate(L/min) | 380L/min / 450L/min / 500L/min |
| Power(KW) | 75kw / 90kw / 110kw / 160kw / 200kw / 250kw / 315kw |
| Power Drive Mode | Electromotor / Diesel engine drive / Hydraulic motor / Power recovery |
| Speed Range | 1000r/min / 0-1500r/min / 0-2500r/min |
| Load location | Liquid control loading / Proportional loading |
| Show location | Locale/ Computer (long-distance) |
| Working Medium | Hydraulic oil |
| Composition | Pressure, flow, speed, displacement and volume, open and closed pumps, left and right rotation items, motors, oil cylinders, torque, power, computer generated test reports, graphs, computer collected data, printouts |
| Applicable area | Apply to performance test of the hydraulic components that supported by a host in engineering machinery, metallurgical, petroleum, machinery, aerospace, shipbuilding and other fields. |
Hydraulic Test Stands, model YST380, manufactured by HIGHLAND are an essential tool for testing hydraulic systems and components. It is a patented product in China Dezhou and is certified by CE. With a pressure rating of 42 Mpa and a power rating of 110 Kw, it is suitable for high-pressure hydraulic system testing and hydraulic pump motor testing. It is also an ideal choice for hydraulic performance test equipment and other testing.
The minimum order quantity for this product is one set and the price varies from USD25000 to 45000. It is packaged in plastic film and delivered within 30 to 60 working days. Payment methods accepted are T/T and Western Union. The supply ability is 5 sets per month.
Hydraulic System Testing Solutions with HIGHLAND YST380 from China Dezhou, certified by CE. Minimum order quantity is 1set with price of USD25000-45000/set, plastic film packaging, delivery time of 30-60 working days, payment terms of T/T, Western Union, supply ability of 5 sets per month. Brand is HIGHLAND, flow rate of 380 L/min, patented product, compact structure, pressure of 42 Mpa.
Hydraulic Test Stands are securely packaged in a cardboard box with bubble wrap to protect against external damage. The box is then sealed with strong packing tape. The box is then placed in a reusable plastic box with an insert to ensure the box does not move during shipping. The plastic box is then sealed with a plastic wrap and placed in a carton for shipping.
The Hydraulic Test Stands are shipped with a carrier approved by the manufacturer. Delivery is typically within 3-5 days after payment is received, and a signature is required upon delivery.
A1: The brand name is HIGHLAND.
A2: The model number is YST380.
A3: The hydraulic test stands come from China Dezhou.
A4: The certification of the hydraulic test stands is CE.
A5: The minimum order quantity for the hydraulic test stands is 1set.
